VIBIA Price list July 2024
Only orders by www.vibia.com or e-mail will be accepted.
A426 _ _ / _ _ _ _ _
_ _ / 00_10 48W + On/ Off + Surface
_ _ / 00_23 48W + On/ Off + Built-in XS
_ _ / 00_31 48W + On/ Off + Remote Micro
_ _ / 01_10 48W + DALI-2 + Surface
_ _ / 01_23 48W + DALI-2 + Built-in XS
_ _ / 01_31 48W + DALI-2 + Remote Micro
_ _ / 03_10 48W + 1-10V + Surface
_ _ / 03_23 48W + 1-10V + Built-in XS
_ _ / 03_31 48W + 1-10V + Remote Micro
_ _ / 05_10 48W + Push + Surface
_ _ / 05_23 48W + Push + Built-in XS
_ _ / 05_31 48W + Push + Remote Micro
_ _ / 0Z_10 48W + Casambi + Surface
_ _ / 0Z_23 48W + Casambi + Built-in XS
_ _ / 0Z_31 48W + Casambi + Remote Micro
A427 _ _ / _ _ _ _ _
_ _ / 00_10 84W + On/ Off + Surface
_ _ / 00_23 84W + On/ Off + Built-in XS
_ _ / 00_31 84W + On/ Off + Remote Micro
_ _ / 01_10 84W + DALI-2 + Surface
_ _ / 01_23 84W + DALI-2 + Built-in XS
_ _ / 01_31 84W + DALI-2 + Remote Micro
_ _ / 03_10 84W + 1-10V + Surface
_ _ / 03_23 84W + 1-10V + Built-in XS
_ _ / 03_31 84W + 1-10V + Remote Micro
_ _ / 05_10 84W + Push + Surface
_ _ / 05_23 84W + Push + Built-in XS
_ _ / 05_31 84W + Push + Remote Micro
_ _ / 0Z_10 84W + Casambi + Surface
_ _ / 0Z_23 84W + Casambi + Built-in XS
_ _ / 0Z_31 84W + Casambi + Remote Micro
Driver for pendant
Materials
Surface: Aluminum.
Built-in and Remote Driver box: Steel.
L 25 cm.
A427 _ _ / 00
A426 _ _ / 01 A427 _ _ / 01
A426 _ _ / 03 A427 _ _ / 03
A426 _ _ / 05 A427 _ _ / 05
A426 _ _ / 0Z A427 _ _ / 0Z
L 21 cm.
A426 _ _ / 00
Electrical connection
Driver Constant Voltage 48V
220~240V 50/60Hz
Notes
Max. 5 luminaires with Simultaneous line 48 W.
Max.10 luminaires with Simultaneous line 84 W.
Select On/ Off if your luminaires are P2P.
Packaging
1 Box 0,12 x 0,10 x 0,37 m
Vol 0,0273 m3
Gross weight 0,95 Kg
Net weight 0,53 Kg
_10 Surface
_23 Built-in XS
_31 Remote
Micro
Select Eletrical connection
Surface
Surface
Included in tracks electrical connections
Surface
Feeder + 9 m
electrical
cable included
Canopy + 9 m
electrical
cable included
Micro canopy + 9 m
electrical
cable included
Built-in
Remote
IP20
Remote Micro
Built-in XS
Finishes
11/ 0 _ Black (NCS S 8500-N)
24/ 0 _ Beige M1 (NCS S 2005-Y50R)
80/ 0 _ Without finish for Built-in and Remote.
