440
Product specifications subject to change without notice. Please check vibia.com for updated information.
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
Ø 13 cm
26,8 cm
max. 200 cm
Bind
Ø 20,5 cm
29 cm
max. 200 cm
Control
Packaging
1 Box 0,28 x 0,26 x 0,13 m
Vol 0,01 m3
Gross weight 2,5 Kg Net weight 2 Kg
Materials
Diffuser: Blown-glass.
Body: Aluminum
Light Source and electronics
1 x LED 4 W 350 mA
Constant Current 350 mA
110~240V 50/60Hz
Finishes (shade)
18/ _ _ Graphite
(ADAPTA RF9913WX)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
58/ _ _ Cream
(RAL 7044)
62/ _ _ Green
(NCS S 3010-G20Y)
Control
Packaging
1 Box 0,28 x 0,26 x 0,13 m
Vol 0,01 m3
Gross weight 2,5 Kg Net weight 2 Kg
Materials
Diffuser: Blown-glass.
Body: Aluminum
Light Source and electronics
1 x LED 4 W 350 mA
Constant Current 350 mA
110~240V 50/60Hz
Finishes (shade)
18/ _ _ Graphite
(ADAPTA RF9913WX)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
58/ _ _ Cream
(RAL 7044)
62/ _ _ Green
(NCS S 3010-G20Y)
IP20
LED
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 415 lm
E
CRI >90
LED Colour Temperature
/1 _ 2700 K - 415 lm
E
CRI >90
6583 _ _ / _ _
6584 _ _ / _ _
_ _ / _ F On/Off; Push; 1-10V; DALI-2;
Casambi Simultaneous Line
_ _ / _ Y ProtoPixel* (P2P)
_ _ / _ Z Casambi (P2P)
6586 _ _ / _ _
6587 _ _ / _ _
_ _ / _ F On/Off; Push; 1-10V; DALI-2;
Casambi Simultaneous Line
_ _ / _ Y ProtoPixel* (P2P)
_ _ / _ Z Casambi (P2P)
Notes
ProtoPixel products are compatible with all other DALI-2
products via a designated gateway (please consult us).
* Available from January 2025.
Extra cable length.
Notes
ProtoPixel products are compatible with all other DALI-2
products via a designated gateway (please consult us).
* Available from January 2025.
Extra cable length.
6583
Black pincer
6584
Beige pincer
6586
Black pincer
6587
Beige pincer
6583
6584
Finishes (pincer)
Black (NCS S 8500-N)
Finishes (pincer)
Beige M1 (NCS S 2005-Y50R)
6586
6587
Finishes (pincer)
Black (NCS S 8500-N)
Finishes (pincer)
Beige M1 (NCS S 2005-Y50R)
