VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
Notes
ProtoPixel products are compatible with all other DALI-2
products via a designated gateway (please consult us).
* Available from January 2025.
Extra cable length.
Notes
ProtoPixel products are compatible with all other DALI-2
products via a designated gateway (please consult us).
* Available from January 2025.
Extra cable length.
Ø 22 cm
11,8 cm
71,2 cm
max. 200 cm
Control
Finishes (shade)
10/ _ _ White
(NCS S 0300-N)
15/ _ _ Grey L2
(NCS S 2500-N
16/ _ _ Grey M1
(NCS S 4500-N)
21/ _ _ Black Grey
(NCS S 7000-N)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
Finish customization
(Available options:
Vibia colour palette
Minimum quantity
10 units. Price + 10%)
Packaging
1 Box 0,29 x 0,38 x 0,38 m
Vol 0,0418 m3
Gross weight 2,6 Kg Net weight 1,4 Kg
Materials
Diffuser: PC- Polycarbonate.
Shade: Aluminum.
Led support: Aluminum.
Tube: Steel.
Light Source and electronics
1 x LED PLATE 10,5 W 15 V
Constant Current 700 mA
110~240V 50/60Hz
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 1170 lm
/2 _ 3000 K - 1251 lm
/3 _ 3500 K - 1251 lm
E
CRI >90
6590 _ _ / _ _
6591 _ _ / _ _
_ _ / _ F On/Off; Push; 1-10V; DALI-2;
Casambi Simultaneous Line
_ _ / _ Y ProtoPixel* (P2P)
_ _ / _ Z Casambi (P2P)
Ø 25 cm
17,7 cm
max. 200 cm
Control
Packaging
1 Box 0,28 x 0,26 x 0,13 m
Vol 0,01 m3
Gross weight 2,5 Kg Net weight 2 Kg
Materials
Diffuser: Blown-glass.
Body: Aluminum
Light Source and electronics
1 x LED 4 W 350 mA
Constant Current 350 mA
110~240V 50/60Hz
Finishes (shade)
18/ _ _ Graphite
(ADAPTA RF9913WX)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
58/ _ _ Cream
(RAL 7044)
62/ _ _ Green
(NCS S 3010-G20Y)
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 415 lm
E
CRI >90
6580 _ _ / _ _
6581 _ _ / _ _
_ _ / _ F On/Off; Push; 1-10V; DALI-2;
Casambi Simultaneous Line
_ _ / _ Y ProtoPixel* (P2P)
_ _ / _ Z Casambi (P2P)
6590
6591
Finishes (pincer)
Black (NCS S 8500-N)
Finishes (pincer)
Beige M1 (NCS S 2005-Y50R)
6580
6581
Finishes (pincer)
Black (NCS S 8500-N)
Finishes (pincer)
Beige M1 (NCS S 2005-Y50R)
6580
Black pincer
6581
Beige pincer
6590
Black pincer
6591
Beige pincer
Only orders by www.vibia.com or e-mail will be accepted.
