437
VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
Ø 30 cm
14 cm
max. 200 cm
Finishes (shade)
10/ _ _ White
(NCS S 0300-N)
11/ _ _ Black
(NCS S 8500-N)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
37/ _ _ Terra Red
(NCS S4040-Y70R)
42/ _ _ Blue M1
(NCS S 1000-N)
47/ _ _ Green L1
(NCS S 4005-G80Y)
Finish customization
(Available options:
Vibia colour palette.
Minimum quantity
10 units. Price + 10%)
Control
Packaging
1 Box 0,29 x 0,38 x 0,38 m
Vol 0,0418 m3
Gross weight 2,6 Kg Net weight 1,4 Kg
Materials
Body: Aluminum.
Diffuser: PMMA .
Light Source and electronics
1 x LED 9,3 W 350 mA
Constant Current 350 mA
110~277V 50/60Hz
6560 _ _ / _ _
6561 _ _ / _ _
_ _ / _ F On/Off; Push; 1-10V; DALI-2;
Casambi Simultaneous Line
_ _ / _ Y ProtoPixel* (P2P)
_ _ / _ Z Casambi (P2P)
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 1269 lm
D
CRI >90
/2 _ 3000 K - 1123 lm
D
CRI >80
/3 _ 3500 K - 1374,9 lm
G
CRI >90
6560
6561
Finishes (pincer)
Black (NCS S 8500-N)
Finishes (pincer)
Beige M1 (NCS S 2005-Y50R)
Notes
ProtoPixel products are compatible with all other DALI-2
products via a designated gateway (please consult us).
* Available from January 2025.
Extra cable length.
6560
Black pincer
6561
Beige pincer
Only orders by www.vibia.com or e-mail will be accepted.
