425
VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
6436
Finishes
11/ _ _ Black
(NCS S 8500-N)
Control
Packaging
1 Box 0,30 x 0,30 x 1,35 m
Vol 0,122 m3
Gross weight 5,8 Kg Net weight 3,8 Kg
Materials
Concave shade: Aluminum.
Diffuser: PC- Polycarbonate.
Structures: Steel.
Canopy: Aluminum.
Light Source and electronics
1 x LED STRIP 27,9 W 750 mA
Constant Current 750 mA
90~305V 50/60Hz
20 cm
122 cm
16 cm max. 200 cm
Notes
Extra cable length.
Dimmer
Multi-volt
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 3154 lm
E
/2 _ 3000 K - 3154 lm
F
/3 _ 3500 K - 3380 lm
E
/7 _ 2200 K - 2703 lm
F
CRI >90
6436 _ _ / _ _
_ _ / _ 1 DALI-2
_ _ / _ 3 1-10V
_ _ / _ 5 Push
_ _ / _ Z Casambi
6438
Finishes
11/ _ _ Black
(NCS S 8500-N)
Control
Packaging
1 Box 0,30 x 0,30 x 1,75 m
Vol 0,158 m3
Gross weight 6,5 Kg Net weight 4 Kg
Materials
Concave shade: Aluminum.
Diffuser: PC- Polycarbonate.
Structures: Steel.
Canopy: Aluminum.
Light Source and electronics
1 x LED STRIP 37,2 W 750 mA
Constant Current 750 mA
90~305V 50/60Hz
20 cm
16 cm
162 cm
max. 200 cm
Notes
Extra cable length.
Dimmer
Multi-volt
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 4205 lm
E
/2 _ 3000 K - 4205 lm
F
/3 _ 3500 K - 4505 lm
E
/7 _ 2200 K - 3604 lm
F
CRI >90
6438 _ _ / _ _
_ _ / _ 1 DALI-2
_ _ / _ 3 1-10V
_ _ / _ 5 Push
_ _ / _ Z Casambi
6474
Finishes
11/ _ _ Black
(NCS S 8500-N)
Control
Packaging
1 Box 0,30 x 0,30 x 1,05 m
Vol 0,095 m3
Gross weight 6,2 Kg Net weight 3,7 Kg
Materials
Glass shade: Opal triplex.
Diffuser: PC- Polycarbonate.
Structures: Steel.
Canopy: Aluminum.
Light Source and electronics
1 x LED STRIP 20,8 W 750 mA
Constant Current 750 mA
90~305V 50/60Hz
Ø 15 cm
92 cm
16 cm max. 200 cm
Notes
Extra cable length.
Dimmer
Multi-volt
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 2381 lm
E
/2 _ 3000 K - 2381 lm
/7 _ 2200 K - 2041 lm
F
CRI >90
6474 _ _ / _ _
_ _ / _ 1 DALI-2
_ _ / _ 3 1-10V
_ _ / _ 5 Push
_ _ / _ Z Casambi
Only orders by www.vibia.com or e-mail will be accepted.
