421
VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
Control
Packaging
1 Box 0,364 x 0,364 x 0,364 m
Vol 0,0482 m3
Gross weight 2,20 Kg Net weight 1,70 Kg
Materials
Body: Aluminum.
Base: Zinc Alloy.
Diffuser: PC- Polycarbonate.
Light Source and electronics
1 x LED 16 W 850 mA
Constant Current 850 mA
220~240Vac 50/60Hz
20 cm
Ø 11 cm
Ø 30 cm
6370
Flat diffuser Surface /
Bolt-down
Dimmer
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 1673 lm
/2 _ 3000 K - 1752 lm
/3 _ 3500 K - 1817 lm
E
CRI >90
6370 _ _ / _ _
_ _ / _ 5 Push
_ _ / _ Y ProtoPixel*
_ _ / _ Z Casambi
Notes
ProtoPixel products are compatible with all
other DALI-2 products via a designated gateway
(please consult us).
*Available from Januray 2025.
Cable with plug included. Electric cable 2 m.
Base: Ø 11 cm. Height 2,8 cm.
Only orders by www.vibia.com or e-mail will be accepted.
360°
70°
Control
Packaging
1 Box 0,26 x 0,26 x 0,26 m
Vol 0,0175 m3
Gross weight 1,31 Kg Net weight 0,89 Kg
Materials
Body: Aluminum.
Base: Zinc Alloy.
Diffuser: PC- Polycarbonate.
Light Source and electronics
1 x LED 7,9 W 450 mA
Constant Current 450 mA
220~240Vac 50/60Hz
14 cm
Ø 8 cm
Ø 20 cm
6365
Flat diffuser Surface /
Bolt-down
Notes
ProtoPixel products are compatible with all
other DALI-2 products via a designated gateway
(please consult us).
*Available from Januray 2025.
Cable with plug included. Electric cable 2 m.
Base: Ø 8,2 cm. Height 2,3 cm.
Dimmer
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 941 lm
/2 _ 3000 K - 987 lm
/3 _ 3500 K - 1022 lm
E
CRI >90
6365 _ _ / _ _
_ _ / _ 5 Push
_ _ / _ Y ProtoPixel*
_ _ / _ Z Casambi
Finishes
11/ _ _ Black
(NCS S 8500-N)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
42/ _ _ Blue M1
(NCS S 5010-B10G)
53/ _ _ Green M1
(NCS S 6005-G80Y)
Finishes
11/ _ _ Black
(NCS S 8500-N)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
42/ _ _ Blue M1
(NCS S 5010-B10G)
53/ _ _ Green M1
(NCS S 6005-G80Y)
