380
Product specifications subject to change without notice. Please check vibia.com for updated information.
With the Tube ceiling collection, Ichiro Iwasaki endeavours
to create a lighting system capable of forming distinctive
expressions by reconfiguring the different constituent parts.
By combining three different diameter shades, six colour
tones and a rhythm of differing heights, Tube creates
a unique landscape of luminaires overhead.
Design by Ichiro Iwasaki
Tube Free
Ceiling
6100
6095
Ø 22 cm
6105
Ø 28,5 cm
Ø 41 cm
Built-in
6095
Control
Ø 22 cm
12 cm
11 cm
Packaging
1 Box 0,26 x 0,26 x 0,26 m
Vol 0,017576 m3
Gross weight 1,6 Kg Net weight 0,8 Kg
Materials
Diffuser: PC- Polycarbonate.
Led support: Aluminum.
Shade: Aluminum.
Canopy: ABS.
Light Source and electronics
2700 K - 3000 K - 3500K:
1 x LED 10,5 W 15 V
Constant Current 700 mA
110~240V 50/60Hz
Bi-volt
IP20
LED
Finishes
15/ _ _ Grey L2
(NCS S 2500-N
16/ _ _ Grey M1
(NCS S 4500-N)
21/ _ _ Black Grey
(NCS S 7000-N)
23/ _ _ Warm White
(NCS S 0502-Y50R)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
Finish customization
(Available options:
Vibia colour palette.
Minimum quantity
10 units. Price + 10%)
LED Colour Temperature
/1 _ 2700 K - 1170 lm
/2 _ 3000 K - 1251 lm
/3 _ 3500 K - 1251 lm
E
CRI >90
6095 _ _ / _ _
_ _ / _ A _ 32 Push; 1-10V;
DALI-2 (Remote)
_ _ / _ Z _ 32 Casambi (Remote)
