359
VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
5905
Finishes
10/ _ _ White
(NCS S 0300-N)
71/ _ _ White, Green
L1, Off-White
(NCS S 0300-N,
NCS S 4005-G80Y,
NCS S 1000-N)
Control
Packaging
1 Box 0,75 x 0,45 x 0,25 m
Vol 0,0844 m3
Gross weight 17,15 Kg Net weight 15,38 Kg
Notes
* Electrical connection point
Materials
Shade: Aluminum.
Diffuser: PC- Polycarbonate.
Structures: Steel.
Canopy: Aluminum.
Light Source and electronics
4 x LED PLATE 13,5 W 700 mA
Constant Current 700 mA
110~240V 50/60Hz
101 cm
Ø 30 cm
Ø 40 cm
Ø 55 cm
18 cm
88 cm
30 cm
*
Ø 11 cm
Dimmer
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 5906 lm
E
/3 _ 3500 K - 6344 lm
F
CRI >90
5905 _ _ / _ A Push; 1-10V; DALI-2
5910
Finishes
10/ _ _ White
(NCS S 0300-N)
72/ _ _ White,
Green L1
(NCS S 0300-N,
NCS S 4005-G80Y)
73/ _ _ White,
Off-White
(NCS S 0300-N,
NCS S 1000-N)
Control
Packaging
1 Box 0,80 x 0,70 x 0,30 m
Vol 0,1680 m3
Gross weight 11,90 Kg Net weight 9,10 Kg
Notes
* Electrical connection point
Materials
Shade: Aluminum.
Diffuser: PC- Polycarbonate.
Structures: Steel.
Canopy: Aluminum.
Light Source and electronics
3 x LED PLATE 13,5 W 700 mA
Constant Current 700 mA
110~240V 50/60Hz
106 cm
Ø 40 cm
Ø 11 cm
Ø 55 cm
90 cm
34 cm
15 cm
*
Dimmer
IP20
LED
LED Colour Temperature
/1 _ 2700 K - 4430 lm
E
/3 _ 3500 K - 4758 lm
F
CRI >90
5910 _ _ / _ A Push; 1-10V; DALI-2
5915
Finishes
10/ _ _ White
(NCS S 0300-N)
Control
Packaging
1 Box 0,65 x 0,65 x 0,25 m
Vol 0,0106 m3
Gross weight 6,80 Kg Net weight 4,73 Kg
Notes
* Electrical connection point
Materials
Shade: Aluminum.
Diffuser: PC- Polycarbonate.
Structures: Steel.
Canopy: Aluminum.
Light Source and electronics
2 x LED PLATE 13,5 W 700 mA
Constant Current 700 mA
110~240V 50/60Hz
Ø 11 cm
Ø 55 cm
29 cm
20 cm
*
Dimmer
LED
Bi-volt
IP20
LED Colour Temperature
/1 _ 2700 K - 2953 lm
E
/3 _ 3500 K - 3172 lm
F
CRI >90
5915 10 / _ A Push; 1-10V; DALI-2
Only orders by www.vibia.com or e-mail will be accepted.
