4878
Finishes
18/ _ _ Graphite
(Adapta RF9913WX)
58/ _ _ Cream
(RAL 7044)
93/ _ _ White
(RAL 9016)
Finish customization
(Available options:
Vibia colour palette.
Minimum quantity
10 units. Price + 10%)
Control
Ø 70 cm
38,5 cm
Ø 28 cm
288
Product specifications subject to change without notice. Please check vibia.com for updated information.
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
Duo
Packaging
1 Box 0,79 x 0,79 x 0,59 m
Vol 0,3682 m3
Gross weight 16 Kg Net weight 14 Kg
Materials
Diffuser: PC- Polycarbonate.
Main Body: Aluminum.
Inner structure: Oak wood.
Light Source and electronics
1 x LED PLATE 26,5 W 700 mA
Constant Current 350 mA
110~240V 50/60Hz
4880
Finishes
18/ _ _ Graphite
(Adapta RF9913WX)
58/ _ _ Cream
(RAL 7044)
93/ _ _ White
(RAL 9016)
Finish customization
(Available options:
Vibia colour palette.
Minimum quantity
10 units. Price + 10%)
Control
Packaging
1 Box 0,79 x 0,79 x 0,59 m
Vol 0,3682 m3
Gross weight 16 Kg Net weight 14 Kg
Materials
Diffuser: PC- Polycarbonate.
Main Body: Aluminum.
Inner structure: Oak wood.
Light Source and electronics
1 x LED PLATE 26,5 W 700 mA
Constant Current 350 mA
110~240V 50/60Hz
Ø 70 cm
30 cm
47,5 cm
Ø 28 cm
Bi-volt
LED
IP20
Bi-volt
LED
IP20
LED Colour Temperature
Static White
/1 _ 2700 K - 2207 lm
/3 _ 3500 K - 2304 lm
F
Tunable White
/8 _ (2200 K - 4000 K)
1901 lm - 2461 lm
G
- F
CRI >90
LED Colour Temperature
Static White
/1 _ 2700 K - 2207 lm
/3 _ 3500 K - 2304 lm
F
Tunable White
/8 _ (2200 K - 4000 K)
1901 lm - 2461 lm
G
- F
CRI >90
4878 _ _ / _ _
_ _ / _ A Static White +
Push; 1-10V; DALI-2
_ _ / _ Z Static White +
Casambi
_ _ / _ 81 Tunable White +
DALI-2 DT8
_ _ / _ 8Z Tunable White +
Casambi
4880 _ _ / _ _
_ _ / _ A Static White +
Push; 1-10V; DALI-2
_ _ / _ Z Static White +
Casambi
_ _ / _ 81 Tunable White +
DALI-2 DT8
_ _ / _ 8Z Tunable White +
Casambi
