261
VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
4500
Control
Packaging
1 Box 0,35 x 0,35 x 0,12 m
Vol 0,0150 m3
Gross weight 1,5 Kg Net weight 1 Kg
Notes
A maximum of 30 modules can be connec-
ted to a single connection point. For bigger
compositions, check connection system
Materials
Shade: ABS.
Diffuser: PC- Polycarbonate.
Lid: PC- Polycarbonate.
Arm: PC- Polycarbonate.
Light Source and electronics
1 x LED STRIP 6,3 W 350 mA
Constant Current 350 mA
110~277V 50/60Hz
30 cm
7 cm
30 cm
Finishes
10/ _ _ White
(NCS S 0300-N)
29/ _ _ Brown D1
(NCS S 8005-Y50R)
38/ _ _ Terra Dark
(NCS S 5040-Y70R)
53/ _ _ Green M1
(NCS S 6005-G80Y)
Each project is unique.
Visit vibia.com and
chose among multiple
compositions designed
and adapted to your
project needs.
Personalise your own
Origami composition
quick and easy at
vibia.com
LED
IP65
LED Colour Temperature
/1 _ 2700 K - 756 lm
D
/3 _ 3500 K - 799 lm
E
CRI >90
4500 _ _ / _ 4 TRIAC
Only orders by www.vibia.com or e-mail will be accepted.
