255
VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
Finishes
18/ _ _ Polymer
Concrete Grey
(NCS S 2002-B50G)
22/ _ _Graphite Black
(NCS S 8000-N)
4136
Control
Packaging
1 Box 0,36 x 0,36 x 0,65 m
Vol 0,084 m3
Gross weight 22 Kg Net weight 19 Kg
Notes
Resistance to weight: 150 kg evenly
distributed over the cantilevered surface
of the lamp. This force should not be applied
by impact.
Materials
Body: Polymer concrete.
Diffuser: PMMA .
Light Source and electronics
2 x LED STRIP 24V 4,3 W
Constant Voltage 24V
100~240V 50/60Hz
3 cm
25 cm
55 cm
25 cm
Finishes
18/ _ _ Polymer
Concrete Grey
(NCS S 2002-B50G)
22/ _ _Graphite Black
(NCS S 8000-N)
4135
Control
Packaging
1 Box 0,36 x 0,36 x 0,36 m
Vol 0,04 m3
Gross weight 12,2 Kg Net weight 10,4 Kg
Notes
Resistance to weight: 150 kg evenly
distributed over the cantilevered surface
of the lamp. This force should not be applied
by impact.
Materials
Body: Polymer concrete.
Diffuser: PMMA .
Light Source and electronics
2 x LED STRIP 24V 4,3 W
Constant Voltage 24V
100~240V 50/60Hz
3 cm
25 cm
25 cm
25 cm
Bi-volt
LED
IP66
Dimmer
LED
Bi-volt
IP66
LED Colour Temperature
/1 _ 2700 K - 304 lm
/3 _ 3500 K - 1247 lm
G
CRI >80 CRI >90
LED Colour Temperature
/1 _ 2700 K - 304 lm
/3 _ 3500 K - 1247 lm
G
CRI >80 CRI >90
4135 _ _ / _ 0 On/ Off
4136 _ _ / _ 0 On/ Off
Only orders by www.vibia.com or e-mail will be accepted.
