Designed to blend instinctively with the architecture in which
it exists, Break Plus converts any wall into a three dimensional mural.
Arranged individually or as a group, it consists of four geometric
volumes that cast beams of diffuse light upwards, downwards -or in
both directions- creating a dynamic dialogue between light and shadow.
Design by Xuclà
Break Plus
Outdoor
4112
4114
4116
4118
12 x 14 cm
12 x 14 cm
21 x 34 cm
19 x 32 cm
4112
4114
Control
Control
Packaging
1 Box 0,07 x 0,19 x 0,23 m
Vol 0,0030 m3
Gross weight 1 Kg Net weight 0,610 Kg
Packaging
1 Box 0,07 x 0,19 x 0,23 m
Vol 0,0030 m3
Gross weight 1 Kg Net weight 0,590 Kg
Materials
Body: Aluminum.
Diffuser: PC- Polycarbonate.
Materials
Body: Aluminum.
Diffuser: PC- Polycarbonate.
Light Source and electronics
1 x LED 1W 350 mA
Constant Current 350 mA
100~240Vac. 50/60Hz
Light Source and electronics
2 x LED 1W 350 mA
Constant Current 350 mA
100~240Vac. 50/60Hz
14 cm
12 cm
6 cm
14 cm
12 cm
6 cm
Finishes
22/ _ _ Graphite Black
(NCS S 8000-N)
25/ _ _ Beige D1
(NCS S 4005-Y50R)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
95/ _ _ Primer
(NCS S 1000-N)
Finishes
22/ _ _ Graphite Black
(NCS S 8000-N)
25/ _ _ Beige D1
(NCS S 4005-Y50R)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
95/ _ _ Primer
(NCS S 1000-N)
Bi-volt
LED
IP65
Bi-volt
LED
IP65
LED Colour Temperature
/1 _ 2700 K - 113 lm
F
/3 _ 3500 K - 146 lm
D
CRI >90
LED Colour Temperature
/1 _ 2700 K - 227 lm
F
/3 _ 3500 K - 292 lm
D
CRI >90
4112 _ _ / _ _
_ _ / _ 0
On/ Off
_ _ / _ 1 _ 30 DALI-2
(Remote)
_ _ / _ Z _ 30 Casambi
(Remote)
4114 _ _ / _ _
_ _ / _ 0
On/ Off
_ _ / _ 1 _ 30 DALI-2
(Remote)
_ _ / _ Z _ 30 Casambi
(Remote)
