250
Product specifications subject to change without notice. Please check vibia.com for updated information.
Break is distinguished by its architectural
attitude. A series of cubic volumes
provide indirect downlight while doubling
up as a dynamic sculptural presence.
Design by Xuclà & Alemany
Break
4101
Finishes
22/ _ _ Graphite Black
(NCS S 8000-N)
80/ _ _ Concrete
(Natural finish)
Control
Packaging
1 Box 0,88 x 0,35 x 0,34 m
Vol 0,1032 m3
Gross weight 38,9 Kg Net weight 35,01 Kg
Materials
Body: Steel.
Head: Concrete.
Base: Concrete.
Diffuser: PMMA .
Light Source and electronics
1 x LED 6,2 W 350 mA
Constant Current 350 mA
100~240V 50/60Hz
25 cm
24 cm
81 cm
18 cm
22 cm
56 cm
4106
Finishes
22/ _ _ Graphite
Black
(NCS S 8000-N)
80/ _ _ Concrete
(Natural finish)
25 cm
24 cm
22 cm
18 cm
43 cm
18 cm
Packaging
1 Box 0,88 x 0,35 x 0,34 m
Vol 0,0598 m3
Gross weight 21,5 Kg Net weight 19,35 Kg
Materials
Head: Concrete.
Base: Concrete.
Diffuser: PMMA .
Light Source and electronics
1 x LED 6,2 W 350 mA
Constant Current 350 mA
100~240V 50/60Hz
Outdoor
25 x 81 cm
25 x 43 cm
4101
4106
48 x 38 cm
4108
Bi-volt
LED
IP66
Bi-volt
LED
IP66
LED Colour Temperature
/1 _ 2700 K - 710 lm
E
CRI >80
LED Colour Temperature
/1 _ 2700 K - 710 lm
E
CRI >80
4101 _ _ / 10 On/ Off
Control
4106 _ _ / 10 On/ Offf
