VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
Control
Control
Packaging
1 Box 1,16 x 0,16 x 0,3 m
Vol 0,487 m3
Gross weight 12,7 Kg Net weight 10,75 Kg
Packaging
1 Box 1,16 x 0,16 x 0,3 m
Vol 0,487 m3
Gross weight 17,9 Kg Net weight 15,8 Kg
Materials
Body: Aluminum.
Shade: Aluminum.
Diffuser: PC- Polycarbonate.
Materials
Body: Aluminum.
Shade: Aluminum.
Diffuser: PC- Polycarbonate.
Light Source and electronics
2700 K - 3500 K:
4 x LED QUADRANT 13,2 W 1050 mA
Constant Current 1050 mA
110~240V 50/60Hz
Tunable White:
4 x LED QUADRANT 13,1 W 1040 mA
Constant Current 1040 mA
220~250V 50/60Hz
Light Source and electronics
2700 K - 3500 K:
4 x LED QUADRANT 24,5 W 1050 mA
Constant Current 1050 mA
110~240V 50/60Hz
Tunable White:
4 x LED QUADRANT 19,78 W 865 mA
Constant Current 865 mA
120~250V 50/60Hz
Finishes
23/ _ _ Beige L1
(NCS S 0502-Y50R)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
53/ _ _ Green M1
(NCS S 6005-G80Y)
Finishes
23/ _ _ Beige L1
(NCS S 0502-Y50R)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
37/ _ _ Terra Red
(NCS S 4040-Y70R)
53/ _ _ Green M1
(NCS S 6005-G80Y)
3905
18 cm
Ø 84 cm
3910
10 cm
Ø 103 cm
Dimmer
LED
Bi-volt
IP20
Dimmer
LED
Bi-volt
IP20
LED Colour Temperature
Static White
/1 _ 2700 K - 7010 lm
D
/3 _ 3500 K - 7729 lm
E
Tunable White
/8 _ (1800 K - 4000 K)
6046 lm - 7404 lm
D
CRI >90
LED Colour Temperature
Static White
/1 _ 2700 K - 13665 lm
/3 _ 3500 K - 14301 lm
Tunable White
/8 _ (1800 K - 4000 K)
10244 lm - 12708 lm
D
CRI >90
3905 _ _ / _ _
_ _ / _ A Static White +
Push; 1-10V; DALI-2
_ _ / _ Z Static White +
Casambi
_ _ / 81
Tunable White +
DALI-2 DT8
_ _ / 8Z Tunable White +
Casambi
3910 _ _ / _ _
_ _ / _ A Static White +
Push; 1-10V; DALI-2
_ _ / _ Z Static White +
Casambi
_ _ / 81
Tunable White +
DALI-2 DT8
_ _ / 8Z Tunable White +
Casambi
Only orders by www.vibia.com or e-mail will be accepted.
