221
VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
27 cm
4 cm
6 cm
Notes
For Tunable White versions, a grouping driver
is recommended.
Visit vibia.com to group several pieces with
just one electrical point.
Finishes
11/ _ _ Black
(NCS S 8500-N)
23/ _ _ Warm White
(NCS S 0502-Y50R)
Control
Packaging
1 Box 0,105 x 0,08 x 0,325 m
Vol 0,015 m3
Gross weight 0,55 Kg Net weight 0,45 Kg
Materials
Frame: PC- Polycarbonate.
Body: Aluminum & PC-Polycarbonate.
Lens: PMMA. Shade: PC- Polycarbonate.
Light Source and electronics
2700 K - 3000 K - 3500K:
1 x LED STRIP 13,3 W 500 mA
Constant Current 500 mA
220~240V 50/60Hz
Tunable White:
1 x LED STRIP 11,5 W
Constant Voltage 24VDC
220~240V 50/60Hz
3575
TRIM
LED Colour Temperature
Static White
/1 _ 2700 K - 1392 lm
/2 _ 3000 K - 1430 lm
/3 _ 3500 K - 1455 lm
Tunable White
/8 _ (2200 K - 4000 K)
764 lm - 849 lm
F
CRI >90
1 m
H
1/3 H
H 2,5 m x 1 m 75 lx
H
4 m x 1m 33 lx
H = 2,5 m
H = 4 m
LED
IP20
26,2 x 3,5 cm
Only orders by www.vibia.com or e-mail will be accepted.
3575 _ _ / _ _
_ _ / _ 0 Static White +
On/ Off
_ _ / _ D Static White +
Push, DALI-2
_ _ / _ M Static White +
Without driver
_ _ / _ Z Static White +
Casambi
_ _ / 81 Tunable White +
DALI-2 DT8
_ _ / 8M Tunable White +
Without driver
_ _ / 8Z Tunable White +
Casambi
