213
VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
Finishes
11/ _ _ Black
(NCS S 8500-N)
23/ _ _ Warm White
(NCS S 0502-Y50R)
Control
27 cm
4 cm
5 cm
Notes
For Tunable White versions, a grouping driver
is recommended.
Visit vibia.com to group several pieces with just
one electrical point.
Packaging
1 Box 0,105 x 0,08 x 0,325 m
Vol 0,003 m3
Gross weight 0,55 Kg Net weight 0,45 Kg
Materials
Body: Aluminum & PC-Polycarbonate.
Shade: PC - Polycarbonate.
Light Source and electronics
2700 K - 3000 K - 3500K:
1 x LED STRIP 13,7 W 650 mA
Constant Current 650 mA
220~240V 50/60Hz
Tunable White:
1 x LED STRIP 13,7 W
Constant Voltage 24VDC
220~240V 50/60Hz
LED Colour Temperature
Static White
/1 _ 2700 K - 1674 lm
/2 _ 3000 K - 1733 lm
/3 _ 3500 K - 1791 lm
Tunable White
/8 _ (2200 K - 4000 K)
1262 lm - 1707 lm
E
CRI >90
d 1 ,4 m x D 1,5 m
418 lx
d 2,8 m x D 3 m
104 lx
d 1,4 m
d 2,8 m
D 3 m
D 1,5 m
H = 1,5 m
H = 3 m
LED
IP20
26,2 x 3,5 cm
Only orders by www.vibia.com or e-mail will be accepted.
3555 _ _ / _ _
_ _ / _ 0 Static White +
On/ Off
_ _ / _ D Static White +
Push, DALI-2
_ _ / _ M Static White +
Without driver
_ _ / _ Z Static White +
Casambi
_ _ / 81 Tunable White +
DALI-2 DT8
_ _ / 8M Tunable White +
Without driver
_ _ / 8Z Tunable White +
Casambi
3555
TRIM
UGR <18
