Finishes
11/ _ _ Black
(NCS S 8500-N)
23/ _ _ Warm White
(NCS S 0502-Y50R)
Control
Materials
Body: Aluminum / PC- Polycarbonate.
Shade: PC- Polycarbonate & Bronze.
Diffuser: PE- Polyethylene.
Frame: PC- Polycarbonate.
Light Source and electronics
2700 K - 3000 K - 3500K:
1 x LED STRIP 7,4 W 350 mA
Constant Current 350 mA
220~240V 50/60Hz
Tunable White:
1 x LED STRIP 7,2 W
Constant Voltage 24VDC
220~240V 50/60Hz
14 cm
4 cm
5 cm
LED Colour Temperature
Static White
/1 _ 2700 K - 897 lm
/2 _ 3000 K - 928 lm
/3 _ 3500 K - 960 lm
E
Tunable White
/8 _ (2200 K - 4000 K)
642 lm - 701 lm
F
CRI >90
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
3500 _ _ / _ _
_ _ / _ 0 Static White + On/ Off
_ _ / _ D Static White + Push, DALI-2
_ _ / _ M Without driver
_ _ / _ Z Static White + Casambi
_ _ / 81
Tunable White + DALI-2 DT8
_ _ / 8M Tunable White + Without driver
_ _ / 8Z Tunable White + Casambi
3503 _ _ / _ _
_ _ / _ 0 Static White + On/ Off
_ _ / _ D Static White + Push, DALI-2
_ _ / _ M Without driver
_ _ / _ Z Static White + Casambi
_ _ / 81
Tunable White + DALI-2 DT8
_ _ / 8M Tunable White + Without driver
_ _ / 8Z Tunable White + Casambi
Finishes
11/ _ _ Black
(NCS S 8500-N)
23/ _ _ Warm White
(NCS S 0502-Y50R)
Control
Packaging
2 Boxes
Vol 0,006 m3
Gross weigth 0,825kg Net weight 0,525 kg
Notes
Trimless frame can be shipped in advance under request.
For Tunable White versions, remote driver only required.
For Tunable White versions, a grouping driver
is recommended.
Visit vibia.com to group several pieces with just one
electrical point.
Materials
Body: Aluminum / PC- Polycarbonate.
Shade: PC- Polycarbonate & Bronze.
Diffuser: PE- Polyethylene.
Trimless frame: Aluminum.
Light Source and electronics
2700 K - 3000 K - 3500K:
1 x LED STRIP 7,4 W 350 mA
Constant Current 350 mA
220~240V 50/60Hz
Tunable White:
1 x LED STRIP 7,2 W
Constant Voltage 24VDC
220~240V 50/60Hz
13 cm
3 cm
7 cm
LED Colour Temperature
Static White
/1 _ 2700 K - 897 lm
/2 _ 3000 K - 928 lm
/3 _ 3500 K - 960 lm
E
Tunable White
/8 _ (2200 K - 4000 K)
642 lm - 701 lm
F
CRI >90
201
VIBIA Price list July 2024
Packaging
1 Box 0,105 x 0,08 x 0,325 m
Vol 0,003 m3
Gross weight 0,5 Kg Net weight 0,35 Kg
Notes
For Tunable White versions, a grouping driver
is recommended.
Visit vibia.com to group several pieces with
just one electrical point.
LED
IP20
13,5 x 3,5 cm
LED
IP20
14,5 x 4 cm
Only orders by www.vibia.com or e-mail will be accepted.
3500
TRIM
UGR <21
3503
TRIMLESS
UGR <21
