182
Product specifications subject to change without notice. Please check vibia.com for updated information.
Structural
Packaging
1 Box 0,34 x 0,34 x 0,25 m
Vol 0,029 m3
Gross weight 4,35 Kg Net weight 2,9 Kg
Materials
Diffuser: PC- Polycarbonate.
Main body: Aluminum.
Structures: Aluminum.
Light Source and electronics
1 x LED PLATE 24V 15 W
Constant Voltage 24V
110~240V 50/60Hz
Packaging
1 Box 0,58 x 0,34 x 0,23 m
Vol 0,045 m3
Gross weight 5,85 Kg Net weight 3,9 Kg
Materials
Diffuser: PC- Polycarbonate.
Main body: Aluminum.
Structures: Aluminum.
Light Source and electronics
1 x LED PLATE 24V 30 W
Constant Voltage 24V
110~240V 50/60Hz
2640
18 cm
24 cm
21 cm
12 cm
15 cm
37 cm
120 cm
1,2 cm
*
Packaging
3 Boxes
Total Vol 0,15 m3
Gross weight 8,25 Kg Net weight 5,5 Kg
Notes
* Electrical connection point.
Materials
Diffuser: PC- Polycarbonate.
Main body: Aluminum.
Structures: Aluminum.
Light Source and electronics
1 x LED PLATE 24V 9 W
1 x LED PLATE 24V 15 W
Constant Voltage 24V
110~240V 50/60Hz
2632
2634
15 cm
24 cm
24 cm
24 cm
48 cm
13 cm
Finishes
15/ _ _ Grey L2
(NCS S 2500-N)
21/ _ _ Black Grey
(NCS S 7000-N)
Finish customization
(Available options:
Vibia colour palette.
Minimum quantity
10 units. Price + 10%)
Finishes
15/ _ _ Grey L2
(NCS S 2500-N)
21/ _ _ Black Grey
(NCS S 7000-N)
Finish customization
(Available options:
Vibia colour palette.
Minimum quantity
10 units. Price + 10%)
Finishes
15/ _ _ Grey L2
(NCS S 2500-N)
21/ _ _ Black Grey
(NCS S 7000-N)
Finish customization
(Available options:
Vibia colour palette.
Minimum quantity
10 units. Price + 10%)
Control
Control
Control
LED Colour Temperature
Static White
/1 _ 2700 K - 2049 lm
E
/2 _ 3000 K - 2214 lm
/3 _ 3500 K - 2233 lm
D
Tunable White
/8 _ (2200 K - 4000 K)
1699 lm - 2188 lm
F
- E
CRI >90
LED Colour Temperature
Static White
/1 _ 2700 K - 4098 lm
E
/2 _ 3000 K - 4428 lm
/3 _ 3500 K - 4466 lm
D
Tunable White
/8 _ (2200 K - 4000 K)
3398 lm - 4376 lm
F
- E
CRI >90
LED Colour Temperature
Static White
/1 _ 2700 K - 3047 lm
/2 _ 3000 K - 3292 lm
/3 _ 3500 K - 3320 lm
E
Tunable White
/8 _ (2200 K - 4000 K)
2519 lm - 3248 lm
F
- E
CRI >90
Bi-volt
LED
IP20
Bi-volt
LED
IP20
Bi-volt
LED
IP20
2632 _ _ / _ _
_ _ / _ 1 Static White + DALI-2
_ _ / _ 3 Static White + 1-10V
_ _ / _ Z Static White + Casambi
_ _ / 81
Tunable White +
DALI-2 DT8
_ _ / 8Z Tunable White +
Casambi
2634 _ _ / _ _
_ _ / _ 1 Static White + DALI-2
_ _ / _ 3 Static White + 1-10V
_ _ / _ Z Static White + Casambi
_ _ / 81
Tunable White +
DALI-2 DT8
_ _ / 8Z Tunable White +
Casambi
2640 _ _ / _ _
_ _ / _ 1 Static White + DALI-2
_ _ / _ 3 Static White + 1-10V
_ _ / _ Z Static White + Casambi
_ _ / 81
Tunable White +
DALI-2 DT8
_ _ / 8Z Tunable White +
Casambi
