181
VIBIA Price list July 2024
Finish
LED Colour Temperature
Model
1160 10 /1 A
Control
2630
18 cm
21 cm
12 cm
Finishes
15/ _ _ Grey L2
(NCS S 2500-N)
21/ _ _ Black Grey
(NCS S 7000-N)
Finish customization
(Available options:
Vibia colour palette.
Minimum quantity
10 units. Price + 10%)
Control
18 x 21 cm
24 x 15cm
48 x 13 cm
120 x 21 cm
Ceiling
2630
160 x 15 cm
2642
120 x 21 cm
2645
160 x 21 cm
2647
2632
2634
2640
Packaging
1 Box 0, 4 x 0,4 x 0,2 m
Vol 0,032 m3
Gross weight 3,75 Kg Net weight 2,5 Kg
Materials
Diffuser: PC- Polycarbonate.
Main body: Aluminum.
Structures: Aluminum.
Light Source and electronics
1 x LED PLATE 24V 9 W
Constant Voltage 24V
110~240V 50/60Hz
LED Colour Temperature
Static White
/1 _ 2700 K - 998 lm
F
/2 _ 3000 K - 1078 lm
/3 _ 3500 K - 1087 lm
E
Tunable White
/8 _ (2200 K - 4000 K)
820 lm - 1060 lm
G
- F
CRI >90
Bi-volt
LED
IP20
2630 _ _ / _ _
_ _ / _ 1 Static White + DALI-2
_ _ / _ 3 Static White + 1-10V
_ _ / _ Z Static White + Casambi
_ _ / 81
Tunable White +
DALI-2 DT8
_ _ / 8Z Tunable White +
Casambi
Only orders by www.vibia.com or e-mail will be accepted.
