128
Product specifications subject to change without notice. Please check vibia.com for updated information.
Offset
100 cm
3,5 cm
7 cm
159 cm
3,5 cm
7 cm
1772
Control
Control
Materials
Body: Aluminum.
Lens: PMMA.
Light Source and electronics
2 x LED 2,9 W 250 mA
Constant current 250 mA
110~240V 50/60Hz
1774
Packaging
1 Box 0,117 x 0,125 x 2 m
Vol 0,029 m3
Gross weight 4,1 Kg Net weight 2,3 Kg
Materials
Body: Aluminum.
Lens: PMMA.
Light Source and electronics
2 x LED 2,9 W 250 mA
Constant Current 700 mA
110~240V 50/60Hz
Finishes
11/ _ _ Black
(NCS S 8500-N)
23/ _ _ Warm White
(NCS S 0502-Y50R)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
Finishes
11/ _ _ Black
(NCS S 8500-N)
23/ _ _ Warm White
(NCS S 0502-Y50R)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
LED Colour Temperature
/1 _ 2700 K - 451 lm
/2 _ 3000 K - 471 lm
/3 _ 3500 K - 489 lm
E
CRI >90
LED Colour Temperature
/1 _ 2700 K - 451 lm
/2 _ 3000 K - 471 lm
/3 _ 3500 K - 489 lm
E
CRI >90
Packaging
1 Box 0,15 x 0,08 x 1,095 m
Vol 0,0091 m3
Gross weight 2,6 Kg Net weight 1,5 Kg
1772 _ _ / _ _
_ _ / _ 1 DALI-2
_ _ / _ 5 Push
_ _ / _ Z Casambi
1774 _ _ / _ _
_ _ / _ 1 DALI-2
_ _ / _ 5 Push
_ _ / _ Z Casambi
IP20
LED
IP20
LED
