1727
Control
Packaging
1 Box 0,20 x 0,21 x 0,13 m
Vol 0,005 m3
Gross weight 1,2 Kg Net weight 0,6 Kg
Materials
Body: Aluminum.
Light Source and electronics
2 x LED 2,9 W 250 mA
Constant Current 250 mA
220~240V 50/60Hz
15 cm
7 cm
15 cm
Finishes
11/ _ _ Black
(NCS S 8500-N)
23/ _ _ Warm White
(NCS S 0502-Y50R)
24/ _ _ Beige M1
(NCS S 2005-Y50R)
d 0,7 m x D 0,73 m 659 lx
d 1,4 m x D 1,42 m 167 lx
26°
d 0,7 m
d 1,4 m
D 1,42 m
D 0,73 m
H = 1,5 m
H = 3 m
Offset
LED Colour Temperature
/1 _ 2700 K - 902 lm
/2 _ 3000 K - 942 lm
/3 _ 3500 K - 978 lm
E
CRI >90
Notes
ProtoPixel products are compatible with
all other DALI-2 products via a designated
gateway (please consult us).
*Available from January 2025.
IP20
LED
1727 _ _ / _ _
_ _ / _ 1 DALI-2
_ _ / _ 5 Push
_ _ / _ Y ProtoPixel*
_ _ / _ Z Casambi
