156 VOL 2
157 VOL 2
BIND SOLO
CEILING
Lens: PMMA
Body: Aluminum
Ceiling support: Aluminum
11 Black (NCS S 8500-N)
24 Beige M1 (NCS S 2005-Y50R)
For a visually compelling variation,
Bind Solo also offers a superficial Accent
Downlight in various diameters and
lengths. The range of apertures allows
for precise modelling of the space using
light and shadow.
LED Colour Temperature
Ø3 cm
Static White
2700 K - 451 lm
3000 K - 471 lm
3500 K - 489 lm
4,3W
Ø4 cm
Static White
2700 K - 530 lm
3000 K - 554 lm
3500 K - 574 lm
5,2W
Only ref. 6664, 6668, 6684, 6688
Tunable White (1800 K - 4000 K)
308 lm - 504 lm
5,5W
CRI>90
Control
Analog: On/Off; Push
Digital: DALI-2*; DALI-2 DT8*
Smart: Casambi
*DALI-2 products are compatible
(via a designated gateway)
with all ProtoPixel dynamic-light
solution products.
Electrical connection
Remote (Driver included)
Visit vibia.com to group several pieces
with just one electrical point
Accent Downlight
Updated detailed spec sheets
on vibia.com
DOWNLIGHT Ø 3 cm
Ø 3 x 4 cm
Ø 3 x 10 cm
6610 Narrow
6614 Medium
6630 Narrow
6634 Medium
DOWNLIGHT Ø 4 cm
Ø 4 x 7 cm
Ø 4 x 10 cm
6660 Narrow
6664 Medium
6668 Wide
6680 Narrow
6684 Medium
6688 Wide
d 0,7 m
331 lx
D 1,42 m
83 lx
26°
d 0,7 m
D 1,42 m
d 0,98 m
221 lx
D 1,95 m
56 lx
36°
d 0,98 m
D 1,95 m
H = 1,5 m
H = 3 m
Medium
Narrow
d 0,38 m
1574 lx
D 0,75 m
393 lx
16°
d 0,38 m
D 0,75 m
d 0,95 m
335 lx
D
1,9 m
90 lx
35°
d 0,95 m
D 1,9 m
d 1,45 m
163 lx
D 2,9 m
41 lx
52°
d 1,45 m
D 2,9 m
H = 1,5 m
H = 3 m
Wide
Medium
Narrow
