88 VOL 2
89 VOL 2
LINE
Wall Washer
A Wall Washer can be selected to
illuminate a vertical surface with uniform
brightness, accentuate an entrance or
highlight a specific feature. Light reflected
from the matte surface of the wall makes
the space appear brighter and provides
soft, diffuse illumination.
H
1/3 H
1 m
H 2,5 m x 1 m 134 lx
H
4 m x 1m 60 lx
H = 2,5 m
H = 4 m
H
1/3 H
1 m
H 2,5 m x 1 m 232 lx
H
4 m x 1m 107 lx
H = 2,5 m
H =
4 m
1 m
H
1/3 H
H 2,5 m x 1 m 75 lx
H
4 m x 1m 33 lx
H = 2,5 m
H = 4 m
WALL WASHER
3583 Trimless
3588 Trimless
3580 Trim
3585 Trim
3575 Trim
27 x 4 cm
53 x 4 cm
104 x 7 cm
3578 Trimless
26 x 3 cm
51 x 3 cm
102 x 3 cm
TRIMLESS
TRIM
Tunable White lighting allows for
comprehensive temperature regulation.
By controlling the individual LEDs, you can
precisely tune the temperature from warm
to cool white, depending on the desired
atmosphere.
2200 K
4000 K
Tunable White
11 Black (NCS S 8500-N)
23 Warm White (NCS S 0502-Y50R)
Body: Aluminum / PC- Polycarbonate
Shade: PC- Polycarbonate
Diffuser: PE- Polyethylene
Trimless frame: Aluminum
51 cm; 53 cm
Static White
2700 K - 2784 lm
3000 K - 2860 lm
3500 K - 2911 lm
26,6W
Tunable White (2200 K - 4000 K)
1528 lm - 1698 lm 23W
102 cm; 104 cm
Static White
2700 K - 5568 lm
3000 K - 5721 lm
3500 K - 5822 lm
53,2W
Tunable White (2200 K - 4000 K)
3056 lm - 3396lm 46W
CRI>90
Visit vibia.com to group several
pieces with just one electrical point
Updated detailed spec sheets
on vibia.com
Control
Analog: On/ Off; Push; 1-10V
Digital: DALI-2; DALI-2 DT8
Smart: Casambi
Electrical connection
Built-in (Driver included)
LED Colour Temperature
26 cm; 27 cm
Static White
2700 K - 1392 lm
3000 K - 1430 lm
3500 K - 1455 lm
13,3W
Tunable White (2200 K - 4000 K)
764 lm - 849 lm 11,5W
