puk.it | 663
808002
QUBO MAXI COB POLE - 42 WATT 220-240V 50-60HZ
light source
light beam options
lumen output (lm)
lumin. efficacy (lm/w)
3000°K warm-white
cob led
14°
4.950
117.85
cob led
35°
4.752
113.14
cob led
55°
4.560
108.57
4000°K neutral-white
cob led
14°
5.265
125.36
cob led
35°
5.000
119.05
cob led
55°
4.770
113.57
2700°K CCT available on request
Technical data
Wattage
42 WATT
Light source
1 x COB CREE
“CXB 2540” LED
Gross weight 4,90 Kg
Colors options
Textured Grey
RAL 9006
Matt Black
(on request)
Anthracite Grey
RAL 7016
808004
QUBO MAXI HP POLE - 38 WATT 220-240V 50-60HZ
light source
light beam options
lumen output (lm)
lumin. efficacy (lm/w)
3000°K warm-white
high-power led
4°
4.300
113.15
high-power led
10°
4.260
112.10
high-power led
28°
4.210
110.79
high-power led
55°
4000°K neutral-white
high-power led
4°
4.400
115.79
high-power led
10°
4.360
114.74
high-power led
28°
4.310
113.42
high-power led
55°
3.664
96.41
2700°K CCT available on request
Colors options
Textured Grey
RAL 9006
Matt Black
(on request)
Anthracite Grey
RAL 7016
Technical data
Wattage
38 WATT
Light source
6 x CREE
“XHP35” LED
Gross weight 4,90 Kg
Full technical details of
poles and accessories for
poles are available at the
end of the catalogue
BURIED POLES
code
h. mm.
809901
3.500
809902
4.500
809903
5.500
809909
TOP CAP DIAM 76mm.
POLES WITH BASE-PLATE
code
h. mm.
809904
3.000
809905
4.000
809906
5.000
809907
ACC.
809909
TOP CAP DIAM 76mm
POLES & ACCESSORIES
