puk.it | 647
Full technical details of
poles and accessories for
poles are available at the
end of the catalogue
807008
SINGLE RING POLE MEDIUM HP - 20 WATT 220-240V 50-60HZ
light source
light beam options
lumen output (lm)
lumin. efficacy (lm/w)
3000°K warm-white
high-power led
4°
2.050
102.50
high-power led
10°
2.000
100.00
high-power led
28°
1.950
97.50
high-power led
55°
1.658
82.88
4000°K neutral-white
high-power led
4°
2.100
105.00
high-power led
10°
2.050
102.50
high-power led
28°
2.000
100.00
high-power led
55°
1.700
85.00
2700°K CCT available on request
807011
DOUBLE RING POLE MEDIUM HP - 2X20 WATT 220-240V 50-60HZ
light source
light beam options
lumen output (lm)
lumin. efficacy (lm/w)
3000°K warm-white
high-power led
4°
2 x 2.050
102.50
high-power led
10°
2 x 2.000
100.00
high-power led
28°
2 x 1.950
97.50
high-power led
55°
2 x 1.658
82.88
4000°K neutral-white
high-power led
4°
2 x 2.100
105.00
high-power led
10°
2 x 2.050
102.50
high-power led
28°
2 x 2.000
100.00
high-power led
55°
2 x 1.700
85.00
2700°K CCT available on request
BURIED POLES
code
h. mm.
809901
3.500
809902
4.500
809903
5.500
809909
TOP CAP DIAM 76mm.
POLES WITH BASE-PLATE
code
h. mm.
809904
3.000
809905
4.000
809906
5.000
809907
ACC.
809909
TOP CAP DIAM 76mm
POLES & ACCESSORIES
Technical data
Wattage
20 WATT
Light source
3 x CREE
XHP35 LED
Gross weight 3,00 Kg
Colors options
Textured Grey
RAL 9006
Matt Black
(on request)
Anthracite Grey
RAL 7016
Technical data
Wattage
2X20 WATT
Light source
6 x CREE
XHP35 LED
Gross weight 5,50 Kg
Colors options
Textured Grey
RAL 9006
Matt Black
(on request)
Anthracite Grey
RAL 7016
