puk.it | 379
Technical features
Wall applique, to be mounted on an outdoor façade/
wall, with two sides light distribution (up & down).
Luminaire body is made of extruded copper-free
aluminum, secured with die-cast aluminum base
and aluminum fixing bracket, tempered safety glass,
moulded silicone gasket and stainless steel screws.
Built-in LED driver 220-240V 50-60Hz, with nr. 2 x 6
CREE XP-G2 LED. IP65 rating.
TAG MEDIUM 02
402504
Technical data
Wattage
7 WATT
IP Rating
IP65
IK Rating
IK08
Material
High corrosion resistance
extruded copper-free
aluminum body
Coating
Polyester powder coating with
phosphocromating pre-finish
Light source
NR. 2 x 2 CREE XP-G2 LED
Screws
Stainless steel
Transformer
Electronic power supply
220/240V 50/60Hz built-in
Gasket
Silicone rubber
Cable gland
M16 rubber grommet
Glass
Tempered
Gross weight
1,20 Kg
Technical data
Wattage
15 WATT
IP Rating
IP65
IK Rating
IK08
Material
High corrosion resistance
extruded copper-free aluminum
body
Coating
Polyester powder coating with
phosphocromating pre-finish
Light source
NR. 2 x 6 CREE XP-G2 LED
Screws
Stainless steel
Transformer
Electronic power supply
220/240V 50/60Hz built-in
Gasket
Silicone rubber
Cable gland
M16 rubber grommet
Glass
Tempered
Gross weight
2,00 Kg
Finish color options:
Textured Grey
RAL 9006
Anthracite Grey
RAL 7016
Matt Black
(on request)
light source
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
3000°K warm-white
high-power led
15°
2 x 840
112.00
high-power led
55°
2 x 810
108.00
4000°K neutral-white
high-power led
15°
2 x 924
123.20
high-power led
55°
2 x 876
116.80
197 mm
65 mm
50 mm
150 mm
5
DALI
Available on request
