puk.it | 287
Technical data
IP Rating
IP67
IK Rating
IK10
Material
high corrosion resistance
extruded copper-free
aluminum
Coating
anodizing treatment +
protective powder coating
Screws
Stainless steel
Gasket
Silicone rubber
Glass
Tempered
Power cable
1 mt. neoprene power cable
included
DMX cable
DMX in & DMX
out cables included
Technical data
Class
Wattage
10 WATT
Light Source Nr. 12 TUNABLE WHITE 3535
LED
Transformer
Constant voltage 24V DC
remote driver needed
Gross weight 3,00 Kg
201203
LINEAGROUND 300 TRIMLESS HP DMX TUNABLE-WHITE
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
2700K-5600K TUNABLE WHITE
high-power led
15°
650
65.00
high-power led
30°
635
63.50
high-power led
60°
620
62.00
high-power led
10x60°
ELLIPTICAL
635
63.50
Technical data
Class
Wattage
20 WATT
Light Source Nr. 24 TUNABLE-WHITE 3535
LED
Transformer
Electrical power supply
220/240V 50/60Hz built-in
Gross weight 5,50 Kg
201207
LINEAGROUND 600 TRIMLESS HP DMX TUNABLE-WHITE
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
2700K-5600K TUNABLE WHITE
high-power led
15°
1.300
65.00
high-power led
30°
1.270
63.50
high-power led
60°
1.240
62.00
high-power led
10x60°
ELLIPTICAL
1.270
63.50
Finish color options:
Glass
Finish color options:
Glass
290 mm
56 mm
81 mm
LUMINAIRE
RECESS HOUSING
62 mm
109 mm
294 mm
145 mm
580 mm
56 mm
81 mm
LUMINAIRE
RECESS HOUSING
62 mm
109 mm
584 mm
145 mm
