262 | puk.it
201110
LINEAGROUND 900 HP DMX RGBW
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
RGBW 3000K
high-power led
15°
1.140
38.00
high-power led
30°
1.095
36.50
high-power led
60°
1.005
33.50
high-power led
10x60°
ELLIPTICAL
1.095
36.50
201114
LINEAGROUND 1200 HP DMX RGBW
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
RGBW 3000K
high-power led
15°
1.520
38.00
high-power led
30°
1.460
36.50
high-power led
60°
1.340
33.50
high-power led
10x60°
ELLIPTICAL
1.460
36.50
Finish color options:
Matt Black
Finish color options:
Matt Black
Technical data
Class
Wattage
30 WATT
Light Source NR. 36 RGBW 3535 LED
Transformer
Electrical power supply
220/240V 50/60Hz built-in
Gross weight 7,00 Kg
Technical data
Class
Wattage
40 WATT
Light Source Nr. 48 RGBW 3535 LED
Transformer
Electrical power supply
220/240V 50/60Hz built-in
Gross weight 9,50 Kg
LUMINAIRE
900 mm
102 mm
1,50 mm
76 mm
RECESS HOUSING
62 mm
884 mm
109 mm
145 mm
LUMINAIRE
1200 mm
102 mm
1,50 mm
76 mm
RECESS HOUSING
62 mm
1184 mm
109 mm
145 mm
