puk.it | 209
Technical features
5
+/- 15°
5000
Round compact ground-recessed luminaire for
outdoor installation, Phospho-chromatised and
polyester powder coated die-cast copper-free
aluminium body and stainless steel AISI 304
frame, tempered safety glass, moulded silicone
gasket. Built-in LED driver 220-240V 50-60Hz,
with 15 CREE XP-L LED. IP67 rating.
HYDROFLOOR
MAXI COMPACT PRO
201062
Technical data
Wattage
22 WATT
IP Rating
IP67
IK Rating
IK10
Material
High corrosion resistance
die-cast copper-free
aluminum body
Trim
Stainless steel AISI 304
Coating
Polyester powder coating
with phosphocromating
pre-finish
Light source
NR. 15 x 1.5W CREE “XP-G3” LED
Screws
Stainless steel
Transformer
Electronic power supply
220/240V 50/60Hz
built-in
Static weight
resistance
Max 5000 Kg
Gasket
Silicone rubber
Glass
Tempered
Cable gland
Double M20
Adjustable
+/- 15 degrees
Power cable
1 mt. neoprene power cable
included
Gross weight
5,0 Kg
Included
Polypropilene recessing box
included
Technical data
Wattage
40 WATT
IP Rating
IP67
IK Rating
IK10
Material
High corrosion resistance
die-cast copper-free
aluminum body
Trim
Stainless steel AISI 304
Coating
Polyester powder coating
with phosphocromating
pre-finish
Light source
NR. 15 CREE “XP-L” LED
Screws
Stainless steel
Transformer
Electronic power supply
220/240V 50/60Hz
built-in
Static weight
resistance
Max 5000 Kg
Gasket
Silicone rubber
Glass
Tempered
Cable gland
Double M20
Adjustable
+/- 15 degrees
Power cable
1 mt. neoprene power cable
included
Gross weight
5,0 Kg
Included
Polypropilene recessing box
included
Stainless Steel
Finish color options:
Ø 318 mm
HOLE FOR RECESSING Ø 310 mm
136 mm
3 mm
light source*
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
3000°K warm-white
high-power led
10°
3.680
92.00
high-power led
30°
3.500
87.50
high-power led
45° *
3.320
83.00
* Other light colors available on request: Neutral-white, * 45° On Request
DALI
1 - 10V
Available on request
