puk.it | 203
Technical data
Wattage
28 WATT
IP Rating
IP67
IK Rating
IK10
Material
High corrosion resistance
die-cast copper-free
aluminum body
Trim
Stainless steel AISI 304
Coating
Polyester powder coating
with phosphocromating
pre-finish
Light source
6 x CREE “XML”
COLOR RGBW LED
Screws
Stainless steel
DMX
DMX interface integrated
Transformer
Electronic power supply
220/240V 50/60Hz
built-in
Gasket
Silicone rubber
Glass
Tempered
Power cable
1 mt. neoprene power cable
included
DMX cable
DMX IN cable included
Gross weight
5,10 Kg
Ground-recessed luminaire in round shape for
outdoor installation, phospho-chromatised
and polyester powder coated die-cast
copper-free aluminium body and stainless
steel AISI 304 frame, tempered safety glass,
moulded silicone gasket. Built-in LED driver,
DMX driver integrated; with 6 x CREE “XML”
RGBW LED. IP67 rating.
HYDROFLOOR MAXI
DMX RGBW
201034RGBW
Ø 265 mm
HOLE FOR RECESSING Ø 257 mm
195 mm
2 mm
Technical features
5
+/- 15°
DMX
5000
Stainless Steel
Finish color options:
light source
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
RGBW
high-power led
12°
1.000
35.71
high-power led
25°
992
35.43
high-power led
35°
981
35.04
DMX ACCESSORIES
CONTROLLERS, SPLITTERS, ETC…
To be defined together with puk technical department, according to project specifications and after providing installation details.
DALI
Available on request
