puk.it | 145
Technical data
IP Rating
IP67
IK Rating
IK10
Material
High corrosion resistance
die-cast copper-free
aluminum body
Trim
Stainless steel AISI 316
Coating
Polyester powder coating
with phosphocromating
pre-finish
Screws
Stainless steel
Gasket
Silicone rubber
Glass
Tempered
Power cable
1 mt. power cable included
Technical features
5
EXTERNAL TRIM REALIZED
IN STAINLESS STEEL AISI 316L
NO VISIBLE SCREWS ONCE
THE PRODUCT IS INSTALLED
REDUCED WIDTH AT 16 MM FOR
BETTER AESTHETIC IMPACT
16 mm
SPECIAL TILT SYSTEM INTEGRATED
ALLOWING ON SITE ADJUSTMENT
+/- 15 DEG. WITHOUT OPENING
THE LUMINAIRE
EXTRA
NARROW 4°
VERY
NARROW 10°
NARROW
SPOT 18°
MEDIUM 28°
MEDIUM
WIDE 36°
WIDE
FLOOD 60°
ASYMMETRIC
WALL-WASHER
DIFFUSED
8°x170°
LIGHT BEAM OPTIONS
