puk.it | 209
Technical features
Ground-recessed luminaire in round shape for
outdoor installation, phospho-chromatised and
polyester powder coated die-cast copper-free
aluminium body and stainless steel AISI 304
frame, tempered safety glass, moulded silicone
gasket. Symmetrical light distribution with
adjustable optics. Built-in LED driver 220-240V
50-60Hz, with 1 CREE CXB 3050 COB LED.
IP67 rating.
MAXI COB
201069
Technical data
Wattage
32 WATT
IP Rating
IP67
IK Rating
IK10
Material
High corrosion resistance
die-cast copper-free
aluminum body
Trim
Stainless steel AISI 304
Coating
Polyester powder coating
with phosphocromating
pre-finish
Light source
Nr. 1 CREE CXB 3050 COB LED
Screws
Stainless steel
Transformer
Electronic power supply
220/240V 50/60Hz
built-in
Static weight
resistance
Max 5000 Kg
Gasket
Silicone rubber
Glass
Tempered
Cable gland
Double M20
Adjustable
+/- 15 degrees
Power cable
1 mt. neoprene power cable
included
Gross weight
5,50 Kg
Included
Polypropilene recessing box
included
Stainless Steel
Finish color options:
Ø 265 mm
HOLE FOR RECESSING Ø 257 mm
195 mm
2 mm
5
+/- 15°
5000
light source
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
3000°K warm-white
cob led
20°
3.978
124.31
cob led
40°
3.912
122.25
4000°K neutral-white
cob led
20°
4.050
126.56
cob led
40°
4.001
125.03
2700°K CCT available on request
DALI
1 - 10V
Available on request
