puk.it | 133
OTHER VIEW
remote driver selection
brand
manufacturer code
type
watt
IP rate
numbers of fixtures
ALVIT Italy
AL1435S-IP
Constant current 350mA
14W
IP67
min 1 – max 2
ALVIT Italy
AL1450S-IP
Constant current 500mA
14W
IP67
1
TCI Italy
152014/350
Constant current 350mA
17W
IP68
min 1 – max 3
TCI Italy
152014/500
Constant current 500mA
24W
IP68
min 1 – max 3
500 mA – LED POWER 7W
light source
light beam
options
lumen
output (lm)
lumin. efficacy
(lm/w)
3000°K warm-white
high-power led
4°
690
98.57
high-power led
10°
662
94.57
high-power led
28°
642
91.71
4000°K neutral-white
high-power led
4°
703
100.43
high-power led
10°
676
96.57
high-power led
28°
656
93.71
AC044
SPIKE
AC095
HONEYCOMB LOUVER
AC038
TREE STRAP
OPTIONAL
AC127
ANTI-GLARE SNOOT
