266
LEVA SOFFITTO/PARETE 1 WALL/CEILING
32
40
62
32
100
62
LEVA SOFFITTO/PARETE 3 WALL/CEILING
Da completare con alimentatore da installare remoto in scatola di derivazione. Per installazione in Container Minifile ordinare
n.2 LTM210 stafa per fissaggio modulo luminoso all’interno della cassaforma. | To be completed with power supply to be
installed in a remote junction box. To install in Container Minifile order n.2 LTM210 single bracket to fix the lighting module
within the wallbox.
Da completare con alimentatore da installare remoto in scatola di derivazione. Per installazione in Container Minifile
ordinare n.1 LTM210 stafa per fissaggio modulo luminoso all’interno della cassaforma. | To be completed with power
supply to be installed in a remote junction box. To install in Container Minifile order n.1 LTM210 single bracket to fix the
lighting module within the wallbox.
LED
lm prod./beam 3000K
W
mA
Dim.
H
Kg
20°
32°
50°
41°x18°
CODE
2,2
700
32x40
62
0.16
200 186 166 175
LV021.9
/##
LED
lm prod./beam 3000K
W
mA
Dim.
H
Kg
20°
32°
50°
41°x18°
CODE
6,6
700
32x100 62
0.26
601
558 496
526
LV026.9
/##
VERSIONI ALIMENTATORI ESCLUSI-POWER SUPPLIER NOT INCLUDED
VERSIONI DISPONIBILI/AVAILABLE VERSION
FASCIO/BEAM
S Spot
F Flood
W Wide
Z Asymmetric
Per i gradi vedere in tabella -
For degree check the table
DRIVERS VEDI | SEEP. 452
700
/## FINITURA/FINISHING
/01 telaio bianco, ottica nera | white frame, black optic
/02 telaio nero, ottica nera | black frame, black optic
/41 telaio bianco, ottica bianca | white frame, white optic
/42 telaio nero, ottica oro | black frame, gold optic
700
LED
incl.
UGR
<14
CRI
>90
5
700
LED
incl.
UGR
<14
CRI
>90
5
FASCIO/BEAM
S Spot
F Flood
W Wide
KELVIN
27
2700K
30
3000K
35 3500K
40 4000K
TW Tunable white
266
Note: Nella versione Tunable White l’alimentatore è da porre remoto | For the version Tunable White, power
supply to be installed remotely.
DIMMABLE (OPTIONAL)
D
Dali
