SPECIFICATIONS
DIMENSIONS
DIMENSIONS
Fixture Height
23" / 584 mm
Fixture Width
1.3" / 33 mm
Fixture Depth
6" / 152 mm
MATERIAL
Material
Brass or Copper
Finish
Bronze, Hand-Rubbed Antique Brass or
Natural Copper
Weight
3.1 lb
LAMPING
Lamp Type
Integrated LED
Lumens
173
Watts
4.2W
Voltage
12V
Lead Wire
18 AWG, 36"
Dimming
MLV
CCT
2700K
Color Quality
90 CRI
Color Binning
3 Step
Field Serviceable LED
Yes
Operating Temperature
-30°C min -40°C max
LED Lifetime
50,000 Hours
OPTIONS
Mounting
Heavy-Duty Stake, Deck/Surface Mount
WARRANTY
Lifetime warranty on manufacturer defects in
the construction, but normal warranty applies
for bulbs, integrated LEDs and living finishes.
23"
584 mm
6"
152 mm
1.3"
33 mm
1.3"
33 mm
1.3"
33 mm
LIGHT DISTRIBUTION
4'
4.7'
5.4'
Acadia, 4.2W, From the Front
0.5 fc
5.4 lux
105.8 max fc
1138.8 max lux
105.8 max fc
1138.8 max lux
0.2 fc
2.2 lux
0.1 fc
1.1 lux
2.5' 2.9' 3.2'
Acadia, 4.2W, From the Side
0.5 fc
5.4 lux
0.2 fc
2.2 lux
0.1 fc
1.1 lux
ORDERING INFORMATION
PRODUCT
FINISH
LAMP
MOUNTING
SL620 ACADIA
BZ
BRONZE
HAB HAND-RUBBED ANTIQUE BRASS
NC
NATURAL COPPER
L1 INTEGRATED LED 4.2W 90 CRI 2700K
NM NO MOUNT
M1
HEAVY-DUTY STAKE
M2
SURFACE
MOUNTING & ACCESSORIES
HEAVY-DUTY STAKE
SL659
DECK/SURFACE MOUNT
SL668BZ,
SL668HAB,
SL668NC
HEAVY-DUTY STAKE
SL659
63
visualcomfort.com | @visualcomfort
