RECESSED
TRAVERSE FLEX
5.5"
139.8 mm
.75"
18.2 mm
1.125"
28.9 mm
TRAVERSE FLEX
FEATURES & BENEFITS
∙ Designed for superior performance and value
∙ Economical, longer lasting alternative to standard
recessed downlights
∙ Provides visually pleasing, color accurate illumination
(90 CRI)
∙ Easy to install: uses mounting ring, trim snaps into
ring with springs
∙ Standard 120V lighting fixture
∙ Mounts to 4” junction boxes, including pancake
junction box
∙ ENERGY STAR® qualified
∙ Title-24 Compliant
∙ Wet rated for shower ceiling installations
∙ Dimmable down to 3%
Item Number
14620S-15
Item Name
TRAVERSE FLEX
Finish
WHITE (-15)
Color
Temperature
3000K
Lumens Delivered
850
Watts Consumed
13 WATTS
Efficacy
65 LM/W
Color
Rendering Index
90 CRI
Beam Spread
LAMBERTIAN
Rated Average
Life
50,000 HOURS
TO 70%
Dimmable
YES TO 3%
Warm On Dim
YES
Voltage
120V
Power Factor
>.9
Ambient
Operating Temp.
-40°C TO +35°C
Construction
STAMPED ALUMINUM,
POWDER COATED
Lens
POLYCARBONATE SNAP IN
Warranty
5 YEARS
Installation
NEW CONSTRUCTION ON 4" ROUND OR
OCTAGONAL JUNCTION BOX, 4" PANCAKE
Qualifications
EN
WET T24-4
SPECIFICATIONS
DIMMER COMPATIBILITY
Forbes & Lomax
FLR603P
Legrand
RHL743P
Insteon
2477D
Lutron
DVCL-153P, SCL-152P, LECL-153P, CTCL-
153P, MACL-153M, STCL-153, DVRP-253P,
PD-6WCL, PD-5NE, MA-PRO, RRD-6NA,
MRF2-6ELV, RRD-10ND, MRF2S-6CL,
Leviton
TSL06, DW1DK-1BZ, DSL06 SSL7A, 6672,
DSE06-1
5.5"
139.8 mm
.75"
18.2 mm
1.125"
28.9 mm
447
