1047
1046
IP 20
IP 20
IP 20
IP 20
Dali
IP 20
Dali
IP 20
IP20
IK02
NEW
IP20
NEW
Dali
IP 20
IP 20
IP20
NEW
IP20
NEW
ACCESSORIES
DALI UNIVERSAL DIMMER
10-300W
L: 12.02 cm W: 3.02 cm H: 2.16 cm
Material: plastic
• Suitable for R, L, and C thanks to
automatic load detection. DALI power
consumption: 6mA
Output voltage
230V AC
Wattage of
10W
Wattage up to
300W
Variant
Prod. no.
grey
1002221
LED POWER SUPPLY
24V | 24W
220-240V ~50/60Hz
L: 13.7 cm W: 5 cm H: 1.55 cm
Output voltage
24 0
Wattage of
0W
Wattage up to
24W
Number of secondary outputs
1
Variant
Prod. no.
white
1008653
DALI CONTROLLER
24V DC
10V-24V DC
L: 11.6 cm W: 4.2 cm H: 1.8 cm
Material: polycarbonate (PC)
• 1 channel LED strip push-dim and DALI
control
CONTROLLER
LED Stip CCT / RGBW
12V/24V DC
L: 14.5 cm W: 4.65 cm H: 1.6 cm
Material: polycarbonate (PC)
• Brightness control for single-colour LED
strips
• Colour temparture controller for CCT strips
• Full colour control of RGB+CCT strips
• Controllable via Zigbee radio protocol
Output voltage
10-24V DC
Number of secondary outputs
1
Variant
Prod. no.
white/grey
1003106
Output voltage
12-24V DC
Wattage of
48W
Wattage up to
96W
Thermal protection
100°C
Variant
Prod. no.
white
1006348
LED POWER SUPPLY
24V | 36W
220-240V ~50/60Hz
L: 17 cm W: 5.7 cm H: 1.8 cm
Output voltage
24 0
Wattage of
0W
Wattage up to
36W
Number of secondary outputs
1
Variant
Prod. no.
white
1008654
LED POWER SUPPLY
24V | 60W
220-240V ~50/60Hz
L: 17 cm W: 5.7 cm H: 1.8 cm
Output voltage
24 0
Wattage of
0W
Wattage up to
60W
Number of secondary outputs
1
Variant
Prod. no.
white
1008655
