puk.it | 597
Technical data
IP Rating
IP67
IK Rating
IK10
Material
high corrosion resistance
extruded copper-free
aluminum
Coating
anodizing treatment +
protective powder coating
Screws
Stainless steel
Gasket
Silicone rubber
Glass
Tempered
Power cable
1 mt. neoprene power cable
included
DMX cable
DMX in & DMX
out cables included
Technical data
Class
Wattage
20 WATT
Light Source Nr. 24 TUNABLE-WHITE 3535
LED
Transformer
Electrical power supply
220/240V 50/60Hz built-in
Gross weight 3,00 Kg
701507
LINEACEILING 600 HP DMX TUNABLE-WHITE
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
2700K-5600K TUNABLE WHITE
high-power led
15°
1.300
65.00
high-power led
30°
1.270
63.50
high-power led
60°
1.240
62.00
high-power led
10x60°
ELLIPTICAL
1.270
63.50
Finish color options:
Matt Black
Technical data
Class
Wattage
10 WATT
Light Source Nr. 12 TUNABLE WHITE 3535
LED
Transformer
Constant voltage 24V DC
remote driver needed
Gross weight 1,70 Kg
701503
LINEACEILING 300 HP DMX TUNABLE-WHITE
light source
light beam options
lumen
output (lm)
lumin. efficacy (lm/w)
2700K-5600K TUNABLE WHITE
high-power led
15°
650
65.00
high-power led
30°
635
63.50
high-power led
60°
620
62.00
high-power led
10x60°
ELLIPTICAL
635
63.50
Finish color options:
Matt Black
310 mm
76 mm
290 mm
103 mm
1,50 mm
600 mm
76 mm
580 mm
103 mm
1,50 mm
292 mm
HOLE FOR RECESS
65 mm
582 mm
HOLE FOR RECESS
65 mm
