Remote control for hoods
A/301/03
Activated carbon filters
A/076/24
Accessories
AGQ60
L = 600 mm / C = 330 mm
Stainless steel
AGQ100
L = 1000 mm / C = 330 mm
Stainless steel
AGQ120
L = 1200 mm / C = 400 mm
Stainless steel
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-60
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-100
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-120
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-70
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-90
AGQ70
L = 700 mm / C = 330 mm
Stainless steel
AGQ90
L = 900 mm / C = 330 mm
Stainless steel
Flue extension (h. 800 mm)
EA0883004000008
Flue extension (h. 800 mm)
EA0883004000008
Flue extension (h. 800 mm)
EA0883004000008
Flue extension (h. 800 mm)
EA0883009000008
Flue extension (h. 800 mm)
EA0883004000008
AGQ150
L = 1500 mm / C = 400 mm
Stainless steel
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-150
Flue extension (h. 800 mm)
EA0883009000008
General features
• Automatic filter cleaning
warning light
• Automatic delayed shutdown
• Flue outlet hole 15 cm
• Maximum power: 355W
• Energy class A
• AISI 304 stainless steel casing
(stainless steel models only)
• Professional stainless steel
baffle filters
• Maximum air flow 890 m3/h
• Remote control set-up (optional
• Four-speed controls
(3 + intensive)
• Available in extraction or
filtering version
• Front LED lights
Technical data
SPEED
W
Pa
m3/h
dB
1
86
355
270
47
2
153
471
379
56
3
249
514
536
64
4
350
539
890
74
ILVE
298 — 299
Hoods → Professional Plus
