Remote control for hoods
A/301/03
Activated carbon filters
A/076/24
Accessories
AG60
L = 600 mm / C = 250 mm
AG100
L = 1000 mm / C = 250 mm
AG120
L = 1200 mm / C = 400 mm
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-60
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-100
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-120
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-70
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-90
AG70
L = 700 mm / C = 250 mm
AG90
L = 900 mm / C = 250 mm
Flue extension (h. 800 mm)
EA08830100000...*
Flue extension (h. 800 mm)
EA08830100000...*
Flue extension (h. 800 mm)
EA08830100000...*
Flue extension (h. 800 mm)
EA08830060000...*
Flue extension (h. 800 mm)
EA08830100000...*
AG150
L = 1500 mm / C = 400 mm
Stainless steel back panel (h. = 660 mm / sp. = 15 mm)
AP4-150
Flue extension (h. 800 mm)
EA08830060000...*
General features
• Automatic filter cleaning
warning light
• Automatic delayed shutdown
• Flue outlet hole 15 cm
• Maximum power: 355W
• Energy class A
• Painted steel body,
AISI 304 stainless steel body
(only inox version)
• Anodised aluminium filters
• Maximum air flow 890 m3/h
• Remote control set-up (optional)
• Four-speed controls
(3 + intensive)
• Available in extraction or
filtering version
• Front LED lights
Technical data
SPEED
W
Pa
m3/h
dB
1
86
355
270
47
2
153
471
379
56
3
249
514
536
64
4
350
539
890
74
* Complete the flue cover extension code, by entering the following in place of the ellipsis “...” :
00 for White - 01 for Antique White - 08 for Stainless Steel - 10 for Charcoal / Matte - 52 for Burgundy Red - 54 for Blue - 56 for Green
ILVE
296 — 297
Hoods → Nostalgie
