MOTOLUX Motorized Architectural Remote Controlled Lighting
www.formalighting.com
Moto-Gimbalo &
Moto-Gimbalo Zoom
350O
IP20
75
Zoom Spot 7° - 42°
Zoom Spotlights
Moto-Combo &
Moto-Combo Zoom
Moto-Gimbalo
65 - Embossed matt black
10 - Black
54 - Embossed matt white
11 - White
75 - Grey
Moto- Gimbalo is available in 2 different sizes: 60mm and 130mm. The luminaire includes brackets for installation
on ceiling thickness max. 25 mm.
Two remote controlled DC motors drive the movements of the fixture. Moto-Gimbalo 60: tiltable 0-40° in two
directions and rotatable 350°; Moto-Gimbalo 130: Tiltable 0-40° in all directions on a dual axis gimbals. A third
motor controls a special lens, which allows the user to shape the light beam of the Zoom version between 7°-18°.
The movements and the beam shaping of the fixture, as well as the intensity and the colour tuning of the light,
are remote controlled via CASAMBI™ application.
LED Sources:
High Efficacy:
CRI: 90 | CCT: 2700K, 3000K, 3500K, 4000K, Tuneable White from 2700K - 5000K
Accessories:
• Linear spread
• Honeycomb louvre
• Snoot
• Visor
For more information about accessories see page 89.
78
MOTOLUX Motorized Architectural Remote Controlled Lighting
www.formalighting.com
Dimming
Options
DC CASAMBI
DA Dali Dim
D1
0-10V Dim
DX
DMX
DC CASAMBI
CCT
Options
27
2700K
30
3000K
35
3500K
40
4000K
T61 2700K - 5000K
Product
Code
Light Source
Code
LED
Power
Nominal
Lumen
Beam Angle
(BAº)
CRI>90
3000K
High
Efficacy
Moto - Gimbalo 60
M516
MC24
8W
1248 lm
18° / 24° / 36°
M517
Moto - Gimbalo 130
M514
MC37
33W
3726 lm
12° / 22° / 32°
M515
LC37
25W
2985 lm
12° / 27° / 55°
MR21
19W
1948 lm
07° / 21° / 36°
Moto - Gimbalo Zoom 130
M580
HN21
25W
2507 lm
BS (07º - 18º)
M581
MC37
29W
3357 lm
BS (14º - 42º)
1 CCT Option T6 available for code M580, M581.
Please visit our website for detailed information.
Trim
Ø94 [Ø3.70"]
Ø175 [Ø6.89"]
ZOOM
Ø175 [Ø6.89"]
Ø100 [Ø3.94"]
Ø175 [Ø6.89"]
Ø175 [Ø6.89"]
118 mm
[4.65”]
Ø 104 mm
[4.09”]
Trimless
Ø 97 mm
[3.82”]
45 mm
[1.77”]
Ø 187 mm
[Ø 7.36”]
242 mm
[9.53"]
167 mm
[6.57"]
136 mm
[5.35"]
Ø 245mm
[Ø 9.65”]
45 mm
[1.77”]
Ø 172 mm
[Ø 6.77”]
Ø 92 mm
[Ø 3.62"]
Ø 92 mm
[Ø 3.62"]
242 mm
[9.53"]
Ø 104.5 mm
[Ø 4.11"]
45 mm
[1.77”]
110 mm
[4.33”]
Ø 187 mm
[Ø 7.36”]
Ø 245mm
[Ø 9.65”]
45 mm
[1.77”]
110 mm
[4.33”]
Ø 104.5 mm
[Ø 4.11"]
Ø 172 mm
[Ø 6.77”]
118 mm
[4.65”]
Ø 42 mm
[Ø 1.65"]
Ø 42 mm
[Ø 1.65"]
Dual Axis Tilt
+/- 25°
BS: Beam Shaping.
93 mm
[3.66”]
84 mm
[3.31”]
MC37
LC37
MR21
I
I
Light source code
130 mm
[5.11”]
93 mm
[3.66”]
84 mm
[3.31”]
MC37
LC37
MR21
I
I
Light source code
130 mm
[5.11”]
