MOTOLUX Motorized Architectural Remote Controlled Lighting
www.formalighting.com
MOTOLUX Motorized Architectural Remote Controlled Lighting - PRO
DMX
360O
90O
IP20
Moto-Zero
&
Moto-Zero Zoom
Zoom
Zoom Spot 07° - 42°
Zoom Spotlights
Moto-Zero
Moto-Zero PRO are intelligent due to their inbuilt memory, allowing them to instantly recall pre-
recorded position, color temperature, beam angle, and dim level settings previously recorded via
CASAMBI™ Control app. Motorized track mounted spotlight with light head and control gearbox
in cast aluminium. Moto- Zero Pro 130 is inclusive of adapter compatible with 3 phase eurotype
track.
Two DC motors drive movements, offering ±90° vertical tilt and 360° horizontal Pan motion. The
zoom version consists of a third motor that allows light beam adjustment.
LED Sources:
High Efficacy:
CRI: 90 | CCT: 2700K, 3000K, 3500K, 4000K, RGBW,
Tuneable White from 2700K - 6500K & 2700K - 5000K.
Accessories:
• Honeycomb louvre
• Linear spread
• Visor
• Snoot
For more information about accessories see page 88.
65 - Embossed matt black
10 - Black
54 - Embossed matt white
11 - White
38
MOTOLUX Motorized Architectural Remote Controlled Lighting
www.formalighting.com
1 CCT Option T2 available for codes M674. CCT Option T6 available for code M675 only.
2 CCT Option RG available for codes M674 only.
Please visit our website for detailed information.
Control Options:
Motor Control
Dimming Control
A
CASAMBI
C
CASAMBI
M
DMX
X
DMX
A
Dali Dim
1
0-10V Dim
P
PHASE
Product
Code
Light Source
Code
LED
Power
Nominal
Lumen
Beam Angle
(BAº)
CRI>90
3000K
High
Efficacy
Moto-Zero 130
Pro
M674
IC54
42W
5713 lm
10° / 18° / 42°
BR21
28W
3252 lm
07° / 21° / 36°
Moto-Zero Zoom
130 Pro
M675
BN21
25W
2677 lm
BS (07º - 18º)
BC37
29W
3575 lm
BS (14º - 42º)
CCT
Options
27
2700K
30
3000K
35
3500K
40
4000K
T21
2700K - 6500K
T61
2700K - 5000K
RG2
RGBW
+/- 360O
+/- 90O
BS: Beam Shaping.
Ø 130
[5.12"]
Ø 130
[5.12"]
189 mm
[7.44”]
285 mm
[11.22”]
32.5 mm
[1.28”]
190 mm
[7.48”]
113 mm
[4.44”]
189 mm
[7.44”]
276 mm
[10.86”]
180 mm
[7.09”]
113 mm
[4.44”]
32.5 mm
[1.28”]
