T E C H N I C A L I N F O
T E C H N I C A L I N F O
4 7 9
4 7 8
p. 299
p. 299
p. 299
p. 299
p. 299
p. 299
p. 299
p. 299
Ø365
4mt
1720mm
450mm
330mm
NOCTAMBULE SUSPENSION
Finiture
Finishes
Colori
Colors
Konstantin Grcic, 2019
nero · black
F0271000
Potenza · Power 54W
Tensione · Voltage 100-240V
led included
Fonte luminosa · Light source
4 STRIP LED x 9W + 1 COB LED 18W
1545lm 2700K CRI 90
Materiali · Materials
vetro soffiato · blown glass
3 Low Cylinders & Cone
Peso · Weight 18,7 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
Ø365
4mt
2170mm
450mm
330mm
NOCTAMBULE SUSPENSION
Finiture
Finishes
Colori
Colors
Konstantin Grcic, 2019
nero · black
F0272000
Potenza · Power 63W
Tensione · Voltage 100-240V
led included
Fonte luminosa · Light source
5 STRIP LED x 9W + 1 COB LED 18W
1831lm 2700K CRI 90
Materiali · Materials
vetro soffiato · blown glass
4 Low Cylinders & Cone
Peso · Weight 22,7 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
Ø550
4mt
750mm
450mm
260mm
NOCTAMBULE SUSPENSION
Finiture
Finishes
Colori
Colors
Konstantin Grcic, 2019
nero · black
F0263000
Potenza · Power 36W
Tensione · Voltage 100-240V
led included
Fonte luminosa · Light source
2 STRIP LED x 9W + 1 COB LED 18W
1007lm 2700K CRI 90
Materiali · Materials
vetro soffiato · blown glass
1 Low Cylinder & Bowl
Peso · Weight 11,7 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
Ø550
4mt
1200mm
450mm
260mm
NOCTAMBULE SUSPENSION
Finiture
Finishes
Colori
Colors
Konstantin Grcic, 2019
nero · black
F0273000
Potenza · Power 45W
Tensione · Voltage 100-240V
led included
Fonte luminosa · Light source
3 STRIP LED x 9W + 1 COB LED 18W
1293lm 2700K CRI 90
Materiali · Materials
vetro soffiato · blown glass
2 Low Cylinders & Bowl
Peso · Weight 15,7 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
Ø550
4mt
1650mm
450mm
260mm
NOCTAMBULE SUSPENSION
Finiture
Finishes
Colori
Colors
Konstantin Grcic, 2019
nero · black
F0274000
Potenza · Power 54W
Tensione · Voltage 100-240V
led included
Fonte luminosa · Light source
4 STRIP LED x 9W + 1 COB LED 18W
1579lm 2700K CRI 90
Materiali · Materials
vetro soffiato · blown glass
3 Low Cylinders & Bowl
Peso · Weight 19,7 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
Ø550
4mt
2100mm
450mm
260mm
NOCTAMBULE SUSPENSION
Finiture
Finishes
Colori
Colors
Konstantin Grcic, 2019
nero · black
F0275000
Potenza · Power 63W
Tensione · Voltage 100-240V
led included
Fonte luminosa · Light source
5 STRIP LED x 9W + 1 COB LED 18W
1865lm 2700K CRI 90
Materiali · Materials
vetro soffiato · blown glass
4 Low Cylinders & Bowl
Peso · Weight 23,7 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
Ø250
Ø185
4mt
1390mm
450mm
NOCTAMBULE SUSPENSION
Finiture
Finishes
Colori
Colors
Konstantin Grcic, 2019
nero · black
F0276000
Potenza · Power 36W
Tensione · Voltage 100-240V
led included
Fonte luminosa · Light source
4 STRIP LED x 9W 1166lm 2700K
CRI 90
Materiali · Materials
vetro soffiato · blown glass
3 Low Cylinders
Peso · Weight 14,7 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
Ø250
Ø185
4mt
1840mm
450mm
NOCTAMBULE SUSPENSION
Finiture
Finishes
Colori
Colors
Konstantin Grcic, 2019
nero · black
F0277000
Potenza · Power 45W
Tensione · Voltage 100-240V
led included
Fonte luminosa · Light source
5 STRIP LED x 9W 1452lm 2700K
CRI 90
Materiali · Materials
vetro soffiato · blown glass
4 Low Cylinders
Peso · Weight 18,7 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
