RECESSED FRAME
.RF
Reference order 10211.XX.RF.XX.XX.XX.9.XX.XX
REF.
ELECTRIC SYSTEM LENGTH
FINISH
DIFFUSER
POWER
CRI
DOWNLIGHT *2 | LUMEN
WATT
DIMM
MM
.27
.30
.40
.TW *1
K
TW
10211
.03
843
.OP
.MP
.ST
.9
2295
2385
2475
5700-5910
18
38
.DA
.PU
.D1
.04
1124
3060
3180
3300
7600-7880
24
51
.05
1405
3825
3975
4125
9500-9850
30
64
.06
1686
4590
4770
4950
11400-11820
36
76
.07
1967
5355
5565
5775
13300-13790
42
89
.08
2248
6120
6360
6600
15200-15760
48
102
REF.
ELECTRIC SYSTEM LENGTH
FINISH
DIFFUSER
POWER
CRI
DOWNLIGHT *2 | LUMEN
WATT
DIMM
MM
.27
.30
.40
10211
.03
843
.OP
.MP
.HI
.9
4590
4767
4956
36
.DA
.PU
.D1
.04
1124
6120
6356
6608
48
.05
1405
7650
7945
8260
60
.06
1686
9180
9534
9912
72
.07
1967
10710
11123
11564
84
.08
2248
12240
12712
13216
96
*1 Tunable White (.TW) values correspond to 2700K and 6500K - .TW is only available for DALI DT8 dimmable (.DA), CRI 80 (.8) 700mA. Los valores del blanco dinámico (.TW) corresponden a 2700K y
6500K. -.TW solo está disponible con protocolo DALI DT8 (.DA), CRI 80 (.8) 700mA.
*2 Down light (direct light) works at 500mA. La luz directa trabaja a 500mA.
*3 Miter cut diffuser. Difusor a inglete.
Select finish
.WH-WH
.GC-GC
.BK-BK
.BM-BM
.BS-BS
.BC-BC
.CR-CR
.CB-CB
.GY-GY
.VC-VC
.MG-MG
.YM-YM
INCLUDED
PROFILE
46
34
36
REF 10211.RF
JOINTS
OPAL
MICROPRISMATIC
PHOTOMETRY
ALBA
MINI
DIM
OPTIONAL
IK06
220-240 V
50-60 Hz
0º
ALUMINIUM
PC
CRI
REMOTE
LIFE
50000H
0º
INDOOR
IP43
IP20
Reference order XX03.RF.XX
ANGLE JOINT*3
T-JOINT
CROSS JOINT
WALL-CEILING JOINT
FINISH
UL03
UT03
UC03
UV03
LINEAR JOINT
UR03
COMPONENTS
OTHER OPTIONS
COVER KIT
REF.
FINISH
TF03
2x8mm.
COVER KIT FOR
REMOTE DRIVER
REF.
FINISH
CK31
Reference order TF03.RF.XX
Reference order CK31.RF.XX
RF INSTALATION KIT
(Total length - 8mm) x 38mm
70mm
Total length = Electric System Length + 25mm + 2x8mm (Cover kit)
(mm)
Linear Joint Total length = Profile length + 25mm + [2 x 8mm (Cover kit)] + [Nº of UR03 x 8]
(mm)
(mm)
+
Joints, other than Linear joint, require a technical drawing
