SURFACE
.SR
Select finishes
.WH-WH
.BK-BK
Reference order 210014.XX.SR.XX.XX.XX.9.XX.XX
EDGE
REF 210014.SR
PHOTOMETRY
PROFILE
INCLUDED
SR INSTALATION KIT
X 2
50
50
DIM
OPTIONAL
IK06
220-240 V
50-60 Hz
0º
ALUMINIUM
PC
CRI
LIFE
50000H
0º
INDOOR
REMOTE
Reference order TF08.SR.XX
COMPONENTS
COVER KIT
REF.
FINISH
TF08
2x2mm.
JOINTS
LINEAR JOINT
UR08
REF.
ELECTRIC SYSTEM LENGTH
FINISH
DIFFUSER
POWER
CRI
DOWNLIGHT | LUMEN
WATT
DIMM
MM
.27
.30
.40
.TW
K
TW
210014
.03
843
.OP
.ST
.9
2295
2385
2475
5700-5910
18
38
.DA
.PU
.D1
.04
1124
3060
3180
3300
7600-7880
24
51
.05
1405
3825
3975
4125
9500-9850
30
64
.06
1686
4590
4770
4950
11400-11820
36
76
.07
1967
5355
5565
5775
13300-13790
42
89
.08
2248
6120
6360
6600
15200-15760
48
102
IP40
Total length = Electric System Length + 20mm + 2x2mm (Cover kit)
(mm)
OTHER OPTIONS
COVER KIT FOR
REMOTE DRIVER
REF.
FINISH
CK31
Reference order CK31.SR.XX
224
225
