QUAD200 short
quad200-short
arcluce.it
4mm
B
C
A
DIMENSIONS
STANDARD COLOUR
30
Code
Optic
Luminaire
CCT
CRI
Class
Wiring
Power Supply
A
mm
B
mm
C
mm
Code
Optic
Luminaire
Watt Lumen
CRI
CCT
Class
Wiring
Power Supply
A
mm
B
mm
C
mm
0765026C-840-30
spot 9°
32W
4050lm
80
4000K
3
REM-D
700mA
230
124
170
0765024C-840-30
medium 25°
32W
3800lm
80
4000K
3
REM-D
700mA
230
124
170
0765028C-840-30
wide flood 47°
32W
3500lm
80
4000K
3
REM-D
700mA
230
124
170
0765036C-840-30
elliptic 9°x52°
32W
3700lm
80
4000K
3
REM-D
700mA
230
124
170
0765052C-840-30
wall washer Imax=19°
32W
3400lm
80
4000K
3
REM-D
700mA
230
124
170
0765067C-30
spot 9°
31W
RGBW
3
REM-D
4x700mA
230
124
170
0765068C-30
medium 25°
31W
RGBW
3
REM-D
4x700mA
230
124
170
0765069C-30
wide flood 46°
31W
RGBW
3
REM-D
4x700mA
230
124
170
0765070C-30
elliptic 9°x57°
31W
RGBW
3
REM-D
4x700mA
230
124
170
0765066C-30
wall washer Imax=18°
31W
RGBW
3
REM-D
4x700mA
230
124
170
0765024C
medium 25°
H
(m)
Ø
(m)
LUX
(max)
1,0
0,45
17154
2,0
0,89
4289
3,0
1,34
1906
4,0
1,79
1072
5,0
2,24
686
0765036C
elliptic 9°x52°
H
(m)
Ø1
(m)
Ø2
(m)
LUX
(max)
1,0
0,98 0,19 16147
2,0
1,97 0,37
4037
3,0
2,95 0,56
1794
4,0
3,94 0,74
1009
5,0
4,92 0,93
646
0765052C
wall washer Imax=19°
0765026C
spot 9°
H
(m)
Ø
(m)
LUX
(max)
1,0
0,16
86580
2,0
0,33
21645
3,0
0,49
9620
4,0
0,66
5411
5,0
0,82
3463
0765028C
wide flood 47°
H
(m)
Ø
(m)
LUX
(max)
1,0
0,87
5193
2,0
1,73
1298
3,0
2,60
577
4,0
3,46
325
5,0
4,33
208
230
The photo represents the family product range. You can see the correct image of each product (code) on the website.
TRIM ABOVE THE GROUND
Supplied with recessed installation box (1099233X).
These fittings are suitable for the modern
control systems. For the various possibilities,
please see section “Controlling the light”.
Recessed floor fittings
LIGHTING DATA
