Material Features
POLYPROPYLENE
- Material: Polypropylene resin with glass fiber , UV stabilizer.
- Process: injection moulding.
- Shock resistant.
- Light weight.
- 100% recyclable.
POLYETHYLENE
- Material: Resin. Linear low-density polethylene. UL94 HB.
- Process: Rotational Moulding.
- Resistant to UVI. Fattore UV8, equivalent to 8.000 hours of Florida sunlight.
- Resistant to extreme temperatures (-60ºC to + 80ºC) / ( -76ºF to 176ºF)
- Shock Resistant.
- Light weight
- The planters are easily drilLED to make draining holes.
- Recyclable 100%.
POLYCARBONATE
- Material: Polycarbonate resin. Low viscosity, high strength.
- Process: Injection Moulding.
- Shock Resistant.
- Light weight
- Recyclable 100%.
ALUMINIUM (TABLE BASE)
- Material: AISI12 (EN AC-44100).
- Process: Cast aluminum.
- Shock Resistant.
- Recyclable 100%.
- Powder coated cast aluminum.
ALUMINUM (PROFILE)
- Material: 6060 (AlMgSi,3.3206,A96060).
- Process: Aluminum extrusion.
- Shock Resistant.
- Recyclable 100%.
- Lacquered.
TEAK WOOD
- Premium Indonesian teak is durable and exceptionally resistant to the elements
- Natural Teak weathers to a soft, silver-grey patina over time due to the effects of sun and moisture
- Please check the web for maintenance and care of teak
WEATHERED TEAK WOOD
- Premium Indonesian teak is durable and exceptionally resistant to the elements
- Weathered Teak’s hand-applied, wire-brush finish offers an already weathered look
- Please check the web for maintenance and care of teak
PADDED FOAM
Polyurethane foam is suitable for outdoor use and in areas with high humidity.
Perfectly waterproof, high drying capacity, comfortable and easily cleaned.
Properties
Unit
Value
Specifications
Composition
-
100% Polyester
-
Maximum temperature
ºC
110.0
±1.0
Manufacturing process
Dry carded and termal drying
Recyclability
100%, without additives or binding agents
Other caractherics:
•It does not absorb or retain moisture.
•It is not affected by mould, insects or rodents.
•It does not cause irritation to the skin or the mucous membranes.
POLYURETHANE FOAM (UPHOLSTERED FURNITURE)
Furniture made produced with Polyurethane foam injected. The foam has high resilience and durability.
The flexible Polyurethane foam is covered with a elastic cellular net that keeps the original poduct’s
shape after its use. Prevents fungal and bacterial growth.
Mechanical properties.
- Tensile strength resistance: between 3 & 10 (Kp./cm2)
- Compression resistance: between 1,5 & 9 (Kp./cm2)
- Shear strength resistance: between 1 & 5 (Kp./cm2)
- Modulus of elasticity: between 40 & 200 (Kp./cm2)
Fire Retardant certificates: UNE EN 1021-1:15 & UNE EN 1021-2:15, IMO – ANNEX 1 – PART 8 (MARITIME FIRE
SAFETY STANDARDS), UNI 9175:2010, BS 5852:06.
EN | TECHNICAL INFORMATION
Table Tops Features
HPL / SOLID CORE
HPL Tabletops for Mari-sol, Faz and Delta table bases thickness is 10mm ± 0,55.
Thickness
ISO 4586 ½
mm
13 ± 0,55
Density
ISO 1183
Kg/m3
1400 - 1500
Absorción de agua
ISO 4586 ½
%
Weight
2,0 max.
Thickness
2,0 max.
Estabilidad dimensional
a altas temperaturas
ISO 4586 ½
%
Long.
0,25 max.
Trans.
0,55 max.
Hardness
ASTM D 785
HR E
97 ca
Resistencia a la flexión
ISO 178
MPa
MPa
Long.
145 min
Trans
135 min
GLASS
Security tempered glass. Thickness: 10 mm.
Technical Features
Units
Value
Resistant to soft body impact
2(B)2
Resistance against suddne temperature changes
K
40
Resistant to wind, snow and large weight
mm
10
Sound insulation
dB
34 (-1,-3)
Thermal Properties
Thermal Transmittance (value U)
W/(m2,K)
5.6
Light Transmission tV
0.53
Light Refletion pV
0.06/0.06
Solar Transmission tE
0.52
Solar Reflection pE
0.06/0.06
DEKTON®
Ceramic surface with high resistance, suitable for indoor and outdoor use.
Kelya
Entzo
Danae
Flexural tensile
strength or modulus of
rupture
UNE
EN ISO
10545-4
Average flexural
resistance
N/
mm2
46
45
55
Average break load
N
2548
2313
2356
Average break
strength
N
14966
13559
13818
Water absorption,
apparent porosity,
density
UNE
EN ISO
10545-3
Water absroption by
boiling
%
0
0,1
0,1
Water absortion by
vacuum
%
0,1
0,1
0,1
Open porosity
%
0,2
0,2
0,2
Aparent relative
density
g/cm3
2,51
2,61
2,53
Aparent density
g/cm3
2,50
2,61
2,52
Resistance to deep
abrasion
UNE
EN ISO
10545-6
Wear volume
mm3
125
106
115
Impact resistance
UNE
EN ISO
10545-5
Coefficient of
restitution (COR)
-
0,85
0,85
0,85
Determination of linear
thermal expansion
UNE
EN ISO
10545-8
Expansion 30-100ºC
ºC-1
6,5 · 10-6
5,1 · 10-6
6,3 · 10-6
Thermal shock
resistance
UNE
EN ISO
10545-9
Damage
-
ULA (no
dam-
age)
ULA (no
damage)
ULA (no
damage)
Moisture expansion
UNE
EN ISO
10545-10
Expansion max
mm/m
0,1
0,1
0,1
Expansion mid
mm/m
0,0
0,0
0,0
Frost resistance
UNE
EN ISO
10545-12
Damage
-
ULA (no
damage)
ULA (no
damage)
ULA (no
damage)
Fabrics Features
Fabric
Weight
Peso
Flame Resistance
Resistance
Color Fastness
Composition
Maintenance
Symbols
Nautical.
Soft acrylic outdoor fabric with
leather-like texture.
657 gr/m2
EN 1021
CAL TB 117
IMO MSC 307
NFPA 260
DIN 4102 B2
FMVVSS 302
ÖNORM A 3800 TEIL 1
>100.000 cycles
XENOTEST DIN
54004/NTC 1479
ASTM D-4329/ CFFA-
2 c2
Vinyl Coating,
100% Polyester
Backing
Clean using a cotton cloth with neutral
soap 1/9 water solution. Rub dry with a
clean cloth and let dry.
Silvertex.
Soft-shiny acrylic outdoor fabric.
685 gr/m2
EN 1021
CAL TB 117
IMO MSC 307
DIN 4102 B2
NF P 92-503 / M2
UNE 23.727-90 IR/ M2
UNI 9175
NFPA 260
>300.000 cycles
>7 - DIN 54004
NTC 1479
(UV outdoor)
4 - ISO 105B04
Vinyl Coating,
100% Polyester
Backing
Clean using a cotton cloth with neutral
soap 1/9 water solution. Rub dry with a
clean cloth and let dry.
Savane.
An irregular weave reveals its
textural beauty. Suited naturally to
all outdoor furnitures.
400 gr/m2
EN 1021
CAL. TB 117
NFPA 260
BS 5852
50.000 cycles
(UV indoor)
8/8 - ISO 105B02
(UV outdoor)
4-5 - ISO 105B04
100% Acrylic
Clean using a cotton cloth with 1/5
household bleach solution. Remove all
bleach residues with water. Rub dry with
a clean cloth and let dry.
Dralon.
Basic acrylic outdoor fiber for
contract products’ cushions.
185 gr/m2
BS 5852
EN 1021
BS7176 Low hazard
25.000 cycles
(UV indoor)
6-7/8 - ISO 105B02
(water)
5 - ISO 105E03/02/01
100% Acrylic
Clean using a cotton cloth with neutral
soap solution. Rub dry with a clean cloth
and let dry.
Crevin.
Upholistery fabric with a medium
size and elegant weave. 40%
made with recycled PET.
520 gr/m2
EN 1021
BS 5852
CAL TB 117
NFPA 260
60.000 cycles
(water)
4-5 - ISO
105E03/02/01
(UV outdoor)
>6 - ISO 105B04
40% Recycled PET
60% PP
Clean using a cotton cloth with 1/5
household bleach solution. Remove all
bleach residues with water. Rub dry with
a clean cloth and let dry.
Heritage.
Made using 50% of recycled
plastics.
335 gr/m2
BS 5852
UNE 1021
CAL TB 117
NFPA 260
25.000 cycles
(UV indoor)
7-8/8 - ISO 105B02
(UV outdoor)
5/5 - ISO 105B04
50% Recycled
acrylic, 47%
Sunbrella acrylic,
3% PE
Clean using a cotton cloth with neutral
soap solution. Rub dry with a clean cloth
and let dry.
Velum.
Lightweight and semi-transparent
fabrics for curtains. .
165 gr/m2
BS 5852
UNE 1021
CAL TB 117
NFPA 260
-
(UV indoor)
8/8 - ISO 105B02
(UV outdoor)
4-5 - ISO 105B04
100% Acrylic
Clean using a cotton cloth with 1/5
household bleach solution. Remove all
bleach residues with water. Rub dry and
let dry.
Batyline.
breathable acrylic mesh used on
sun loungers and sunroofs.
500 gr/m2
EN 1021 1-2
EN 13501 - 1
DIN 4102 B1
NFP 92-507
CAL TB 117
IMO MSC 307
NFPA 260
>120.000 cycles
4/5
ASTM G154
Polyester fibre
protected with
PVC coating.
Wash the mesh with a mild liquid deter-
gent and fresh water, using a soft bristle
brush. Batyline mesh has anti-fungal
treatment where the moist will have no
effect on it.
Cico.
Cozy fabric with an elegant look
and soft touch.
423 gr/m2
BS 5852
UNE 1021
CAL TB 117
25.000 cycles
(UV indoor)
7/8 - ISO 105B02
(UV outdoor)
4/5 - ISO 105B04
100%
Polypropylene
Clean using a cotton cloth with neutral
soap solution. Rub dry with a clean cloth
and let dry.
Siesta.
Cozy fabric with an elegant look
and soft touch.
500 gr/m2
UNE 1021
CAL TB 117
60.000 cycles
-
100%
Polypropylene
Clean using a cotton cloth with neutral
soap solution. Rub dry with a clean cloth
and let dry.
Acapulco.
Cozy fabric with an elegant look
and soft touch.
500 gr/m2
BS 5852
UNE 1021
CAL TB 117
>30.000 cycles
-
100%
Polypropylene
Clean using a cotton cloth with neutral
soap solution. Rub dry with a clean cloth
and let dry.
Ikon 36.
Cozy fabric with an elegant look
and soft touch.
650 gr/m2
BS 5852
CAL TB 117
30.000 cycles
-
100%
Polypropylene
Clean using a cotton cloth with neutral
soap solution. Rub dry with a clean cloth
and let dry.
Krollet.
Elegant fabric with a pleasant
touch and great comfort.
985 gr/ml
BS 5852
CAL TB 117
40.000 cycles
94% PP + 6 %
PC S.D.
Varm.
Cozy fabric with a pleasant touch
and great comfort.
850 gr/m2
CAL. TB 117
IMO MSC 307
BS 5852
60.000 cycles
Factor 7UV UNI EN ISO
20105-B02
100%
Polypropylene
The whashing podwer should not
contain oxidizing agents o brighten-
ing agents. In case of dropped liquid
or water on the fbric remove all spils
immediately but not the rub. Gently blot
liquid spills with a clean dry cloth
Hygge.
Cozy fabric with a pleasant touch
and great comfort.
910 gr/m2
CAL. TB 117
IMO MSC 307
BS 5852
60.000 cycles
Factor 7UV UNI EN ISO
20105-B02
100%
Polypropylene
Glad.
Premium fabric with a wide range
of colours
975 gr/m2
CAL. TB 117
IMO MSC 307
BS 5852
30.000 cycles
Factor 7UV UNI EN ISO
20105-B02
100%
Polypropylene
