Material / Features
Polypropylene
- Material: Polypropylene resin with glass fiber , UV stabilizer.
- Process: injection moulding.
- Shock resistant.
- Light weight.
- 100% recyclable.
Polyethylene
- Material: resin. Linear low-density polethylene. Ul94 hb.
- Process: rotational moulding.
- Resistant to UVI. fattore UV8, equivalent to 8.000 hours of Florida sunlight.
- Resistant to extreme temperatures (-60ºC to + 80ºC) / ( -76ºF to 176ºF)
- Shock resistant.
- Light weight
- The planters are easily drilled to make draining holes.
- Recyclable 100%.
Polycarbonate
- Material: polycarbonate resin. Low viscosity, high strength.
- Process: injection moulding.
- Shock resistant.
- Light weight
- Recyclable 100%.
Aluminium (table base)
- Material: AISI12 (EN AC-44100).
- Process: cast aluminum.
- Shock resistant.
- Recyclable 100%.
- Powder coated cast aluminum.
Aluminum (profile)
- Material: 6060 (AlMgSi,3.3206,A96060).
- Process: aluminum extrusion.
- Shock resistant.
- Recyclable 100%.
- Lacquered.
Iroko Wood
- Hard and very resistant wood.
- Process: Machining.
- Shock and outdoor resistant.
- Recyclable 100%.
- Varnished to avoid rain stains.
Teak Wood
- Premium Indonesian teak is durable and exceptionally resistant to the elements
- Natural Teak weathers to a soft, silver-grey patina over time due to the effects of sun and
moisture
- Please check the web for maintenance and care of teak
Weathered Teak Wood
- Premium Indonesian teak is durable and exceptionally resistant to the elements
- Weathered Teak’s hand-applied, wire-brush finish offers an already Weathered look
- Please check the web for maintenance and care of teak
Polyurethane Foam (Upholstered Furniture)
Furniture made produced with Polyurethane foam injected. The foam has high resilience and du-
rability. The flexible Polyurethane foam is covered with a elastic cellular net that keeps the original
poduct’s shape after its use. Prevents fungal and bacterial growth.
Mechanical properties.
- Tensile strength resistance: between 3 & 10 (Kp./cm2)
- Compression resistance: between 1,5 & 9 (Kp./cm2)
- Shear strength resistance: between 1 & 5 (Kp./cm2)
- Modulus of elasticity: between 40 & 200 (Kp./cm2)
Table Tops / Features
HPL / Solid Core
HPL Tabletops for Mari-sol, Faz and Delta table bases thickness is 10mm ± 0,55.
Thickness
ISO 4586 ½
mm
13 ± 0,55
Density
ISO 1183
Kg/m3
1400 - 1500
Water absorption
ISO 4586 ½
%
Weight
2,0 max.
Thickness
2,0 max.
Dimensional stability at
high temperatures
ISO 4586 ½
%
Long.
0,25 max.
Trans.
0,55 max.
Hardness
ASTM D 785
HR E
97 ca
Bending strength
ISO 178
MPa
MPa
Long.
145 min
Trans
135 min
Glass
Security tempered glass. Thickness: 10 mm.
Technical Features
Units
Value
Resistant to soft body impact
2(B)2
Resistance against suddne temperature changes
K
40
Resistant to wind, snow and large weight
mm
10
Sound insulation
dB
34 (-1,-3)
Thermal Transmittance (value U)
W/(m2,K)
5.6
Light Transmission tV
0.53
Light Refletion pV
0.06/0.06
Solar Transmission tE
0.52
Solar Reflection pE
0.06/0.06
Concrete
Furniture elements manufactured in high-strength fibrated mortar, by casting and vibrating in
elastomer moulds and rigid fiberglass shell.
- 2.4 g/cm3 density
- Water-repellent protection
- Oil repellent protection
- Diamond abrasive roughening
Technical Information
Fabrics / Features
Technical Information
Padded Foam
Polyurethane foam is suitable for outdoor use and in areas with high humidity. Perfectly water-
proof, high drying capacity, comfortable and easily cleaned.
Properties
Unit
Value
Specifications
Composition
-
100% Polyester
-
Maximum temperature
ºC
110.0
±1.0
Manufacturing process
Dry carded and termal drying
Recyclability
100%, without additives or binding agents
Other caractherics:
- It does not absorb or retain moisture.
- It is not affected by mould, insects or rodents.
- It does not cause irritation to the skin or the mucous membranes.
Fabric
Weight
Flame Resistance
Resistance
Color Fastness
Composition
Maintenance
Symbols
Altea.
Soft acrylic outdoor fabric
with leather-like texture.
657 gr/m2
EN 1021 1-2
DIN 4102 B2
BS 5852
DIN 53438/T2
CAL TB 117
>100.000
cycles
XENOTEST DIN 54004/
NTC 1479
ASTM D-4329/ CFFA-2
c2
Vinyl Coating,
100% Polyester
Backing
Clean using a cotton cloth with
neutral soap 1/9 water solution.
Rub dry with a clean cloth and
let it dry.
Arousa.
Soft-shiny acrylic outdoor
fabric.
685 gr/m2
EN 1021 1-2
DIN 4102 B2
NF P 92-503 / M2
UNE 23.727-90 IR/ M2
IMO MSC.307
CAL TB 117
>300.000
cycles
>7 - DIN 54004
NTC 1479
(UV outdoor)
4 - ISO 105B04
Vinyl Coating,
100% Polyester
Backing
Clean using a cotton cloth with
neutral soap 1/9 water solution.
Rub dry with a clean cloth and
let it dry.
Fabric
Weight
Flame Resistance
Resist-
ance
Color Fastness
Composition
Maintenance
Symbols
Baiona.
High density fabric, which
provides a sense of strength
and an irregular pattern that
adds a handcrafted touch.
*
BS 5852 PART 0 AND 1
(MATCH TEST)
UNE-EN 1021
PART 1 AND 2
IMO MSC.307 (88)
ANEXO 1 PARTE 8 (PEF)
20.000
cycles UNE
EN ISO
12497-
2:2014
7-8 X/ 8 UNE EN ISO 150-
B02:2014 Método 2
7-8 X/ 8 UNE EN ISO 150-
B04:1998
5 X/ 5 UNE EN ISO 105-
E03:2012
100% Solution
Dyed Acrylic
Please refer to the table of
cleaning solutions for specific
fabric stains.
Cl
Calella.
Fabric with a rich and unusual
texture and exceptional
softness, which enhances the
comfort of the furniture.
450
g/m2
*
BS 5852 PART 0 AND 1
(MATCH TEST)
UNE-EN 1021
PART 1 AND 2
IMO MSC.307 (88)
ANEXO 1 PARTE 8 (PEF)
20.000
cycles
UNE
EN ISO
12497-
2:2001
(UV outdoor) 8 / 8 - UNE EN
ISO 105-B02:2014
(chlorinated water) 5 / 5 -
UNE EN ISO 105-E03:2010
100% Solution
Dyed Acrylic
Please refer to the table of
cleaning solutions for specific
fabric stains.
Cl
Fisterra.
Fabric with a very distinctive
irregular mottled pattern and a
soft touch.
600
g/m2
75.000
cycles
UNI EN ISO
12947-2
(UV outdoor) >7 - UNI EN
ISO 105-B02
7 - UNI EN ISO 105-B04
(chlorinated water) 4 / 5 -
UNE EN ISO 105-E03:2010
70%
PC-Acrylic,
30%
PL-Polyester
Please refer to the table of
cleaning solutions for specific
fabric stains.
Portonovo.
Fabric with a clean and simple
design, which adapts to any
decorative style.
280
g/m2
*
BS 5852 PART 0 AND 1
(MATCH TEST)
UNE-EN 1021
PART 1 AND 2
IMO MSC.307 (88)
ANEXO 1 PARTE 8 (PEF)
20.000
cycles
UNE
EN ISO
12497-
2:2001
(UV outdoor) 7 / 8 - UNE EN
ISO 105 - B02 : 2014
(chlorinated water) 5 / 5 -
UNE EN ISO 105-E03:2010
100% Solution
Dyed Acrylic
Please refer to the table of
cleaning solutions for specific
fabric stains.
Cl
Curtain Fabric 1.
Lightweight and semi-
transparent fabrics for curtains.
165
g/m2
-
-
(UV indoor)
8/8 - ISO 105B02
(UV outdoor)
4-5 - ISO 105B04
100% Acrylic
Clean using a cotton cloth with
1/5 household bleach solution.
Remove all bleach residues with
water. Rub dry and let dry.
Curtain Fabric 2.
Lightweight and semi-
transparent fabrics for curtains.
Please refer to the table of
cleaning solutions for specific
fabric stains.
Breathable Fabric.
Breathable acrylic mesh used
in sun loungers and sunroofs
500
g/m2
EN 1021 1-2
EN 13501 - 1
DIN 4102 B1
NFP 92-507
CAL TB 117
IMO MSC 307
>120.000
cycles
4/5
ASTM G154
Polyester fibre
protected with
PVC coating.
Wash the mesh with a mild liquid
detergent and fresh water, using
a soft bristle brush. Batyline
mesh has anti-fungal treatment
where the moist will have no
effect on it.
Ribadeo.
Fabric whose marbled yarns
of different thicknesses create
a rich and visually interesting
texture. Natural style, linen look.
657
g/m2
BS 582-1-EN-1020-1
80.000
cycles
UNI EN ISO
12947-2
(UV outdoor) >7 - UNI EN
ISO 105-B02
7 - UNI EN ISO 105-B04
(chlorinated water) 4 / 5 -
UNE EN ISO 105-E03:2010
70%
PC-Acrylic,
30%
PL-Polyester
Please refer to the table of
cleaning solutions for specific
fabric stains.
Louro.
Soft and versatile fabric. It
has a neutral base color that
makes it easy to integrate with
different colors and fabrics.
557
g/m2
BS 582-1-EN-1020-1
65.000
cycles
UNI EN ISO
12947-2
(UV outdoor) >7 - UNI EN
ISO 105-B02
7 - UNI EN ISO 105-B04
(chlorinated water) 4 / 5 -
UNE EN ISO 105-E03:2010
65%
PC-Acrylic,
35%
PL-Polyester
Please refer to the table of
cleaning solutions for specific
fabric stains.
Suances.
Soft and warm terry fabric with
color combinations that add
depth and elegance.
585
g/m2
BS 582-1-EN-1020-1
40.000
cycles
UNI EN ISO
12947-2
(UV outdoor) >7 - UNI EN
ISO 105-B02
7 - UNI EN ISO 105-B04
(chlorinated water) 4 / 5 -
UNE EN ISO 105-E03:2010
90%
PC-Acrylic,
10%
PL-Polyester
Please refer to the table of
cleaning solutions for specific
fabric stains.
Getaria.
Premium fabric with a wide
range of colours
>30.000
100% solution
dyed acrylic
Please refer to the table of
cleaning solutions for specific
fabric stains.
Zumaia.
Elegant fabric with a pleasant
touch and great comfort.
985
gr/ml
BS 5852
CAL TB 117
40.000
cycles
94% PP + 6 %
PC S.D.
Please refer to the table of
cleaning solutions for specific
fabric stains.
Moraira.
Fabric with an original striped
design and a versatile
selection of colors, great for
adding a distinctive touch.
564
g/m2
BS 582-1-EN-1020
50.000
cycles
UNI EN ISO
12947-2
(UV outdoor) >7 - UNI EN
ISO 105-B02
7 - UNI EN ISO 105-B04
(chlorinated water) 4 / 5 -
UNE EN ISO 105-E03:2010
90%
PC-Acrylic,
10%
PL-Polyester
Please refer to the table of
cleaning solutions for specific
fabric stains.
Teguise.
Fabric with a contrasting
striped design and colors
in harmony with the rest of
fabrics and finishes.
607
g/m2
BS 582-1-1EN-1020
50.000
cycles
UNI EN ISO
12947-2
(UV outdoor) >7 - UNI EN
ISO 105-B02
7 - UNI EN ISO 105-B04
(chlorinated water) 4 / 5 -
UNE EN ISO 105-E03:2010
70%
PC-Acrylic,
30%
PL-Polyester
Please refer to the table of
cleaning solutions for specific
fabric stains.
Roses.
Small terry fabric, whose
neutral colors allow an
easy integration with other
collections.
460
g/m2
NFPA 260
EN 1021-1
BS 5852-1(S4)
CA TB 117
45.000
cycles UNE
EN ISO
12947-2
(UV indoor) 7 / 8 - UNE EN
ISO 105-B02
(chlorinated water) 5 / 5 -
UNE EN ISO 105-E03:2010
100% Solution
Dyed Acrylic
Please refer to the table of
cleaning solutions for specific
fabric stains.
40
Cl
Llanes.
Fabric with a classic striped
design that combines
elegance and functionality.
280
g/m2
*
BS 5852 PART 0 AND 1
(MATCH TEST)
UNE-EN 1021 PART 1
AND 2
IMO MSC.307 (88)
ANEXO 1 PARTE 8 (PEF)
20.000
cycles
UNE
EN ISO
12497-
2:2001
(UV outdoor) 7 / 8 - UNE EN
ISO 105-B02:2014
(chlorinated water) 5 / 5 -
UNE EN ISO 105-E03:2010
100% Solution
Dyed Acrylic
Please refer to the table of
cleaning solutions for specific
fabric stains.
Cl
* On request, with supplement.
