SPECIFICATIONS
DIMENSIONS
DIMENSIONS
Fixture Height
1.3" / 25 mm
Fixture Width
1.5" / 51 mm
MATERIAL
Material
Brass or Copper
Finish
Bronze, Hand-Rubbed Antique Brass or
Natural Copper
Weight
.4 lbs
LAMPING
Lamp Type
Integrated LED
Lumens
307
Watts
4.2W
Voltage
12V
Lead Wire
18 AWG, 36"
Dimming
MLV
CCT
2700K
Color Quality
90 CRI
Color Binning
3 Step
Field Serviceable LED
No
Operating Temperature
-30°C min -40°C max
LED Lifetime
50,000 Hours
OPTIONS
Mounting
Deck/Surface Mount, 5" Stainless Steel Spikes
Accessory
Micro Spot Flange
WARRANTY
Lifetime warranty on manufacturer defects in
the construction, but normal warranty applies
for bulbs, integrated LEDs and living finishes.
ORDERING INFORMATION
PRODUCT
FINISH
LAMP
MOUNTING
ACCESSORY
SL629 DELPHINI MICRO FIXED IN-GRADE
BZ
BRONZE
HAB HAND-RUBBED ANTIQUE BRASS
NC
NATURAL COPPER
L1 INTEGRATED LED 4.2W
90 CRI 2700K
M2 SURFACE
M9 5" STAINLESS
STEEL SPIKES
NF NO FLANGE
F1
FLANGE*
*FLANGED CANNOT BE INSTALLED AS A SURFACE MOUNT.
1"
25 mm
1.1"
28 mm
1.3"
33 mm
1.3"
33 mm
1.5"
51 mm
2.4"
61 mm
1.7"
43 mm
MOUNTING & ACCESSORIES
5" STAINLESS
STEEL SPIKES
SL690
FLANGE
SL692BZ,
SL692HAB,
SL692NC
DECK/SURFACE
MOUNT
SL668HAB,
SL668BZ,
SL668NC
1"
25 mm
1.1"
28 mm
1.3"
33 mm
1.3"
33 mm
1.5"
51 mm
2.4"
61 mm
1.7"
43 mm
