2700K VIVID I
49274S-15
49275S-15
49276S-15
49277S-15
49278S-15
3000K VIVID I
49374S-15
49375S-15
49376S-15
49377S-15
49378S-15
3000K VIVID II
495193S-15
495293S-15
495393S-15
495493S-15
495593S-15
Length
7.5"
12"
18"
24"
30"
Voltage
120V DIRECT WIRE
Lumens (@ 3000K)
VIVID I: 343
VIVID I: 575
VIVID I: 900
VIVID I: 1245
VIVID I: 1461
VIVID II: 350, 575, 900, 1250, and 1450
Power Consumption
VIVID I: 6.4W
VIVID I: 9.7W
VIVID I: 15.5W
VIVID I: 20.6W
VIVID I: 26W
VIVID II: 5.1W, 8.1W, 12.2W, 16.7W, and 21W
Efficacy
VIVID I: 54 LM/W
VIVID I: 59 LM/W
VIVID I: 58 LM/W
VIVID I: 60 LM/W
VIVID I: 55 LM/W
VIVID II: 69, 71, 74, 75, AND 69 LM/W
Color Rendering Index
90 CRI
Rated Average Life
50,000 HOURS TO 70%
Dimming range(1)
DOWN TO 10%
Installation
HARD WIRE OR PLUG IN WITH OPTIONAL POWER CORD ACCESSORY. LINK MULTIPLE UNITS WITH OPTIONAL
CONNECTOR CORDS.
Certification
EN
T24-1
Features
LOCAL ON/OFF SWITCH
(1) Vivid 120V LED is dimmable with a standard incandescent or electronic low voltage (ELV) dimmer. When sizing dimmer consult
with the dimmer manufacturer for information on de-rating the dimmer for in-rush current.
30"
762 mm
24"
610 mm
18"
457 mm
12"
305 mm
7.5"
190 mm
1"
25 mm
3.1"
79 mm
VIVID 120V LED 12"
The Vivid LED Undercabinet series takes the classic
xenon or fluorescent undercabinet light to the next
level. Using high quality LED technology, these fixtures
achieve great light output and a high level of energy
efficiency at an extremely affordable price point.
VIVID 120V LED
LIGHTING SYSTEMS
LIGHTING SYSTEMS
VIVID 120V LED
410
